The General Electric IS230TRLSH2B is a specialized relay output terminal board module designed for the Mark VIe control system platform. This Relay Output Module interfaces with control processors to safely drive field solenoids, control valves, motor starters, and external interlock circuits across heavy industrial environments. Operating as a component within the distributed control architecture, it receives digital commands from the system controller and converts them into physical, isolated dry contact closures or voltage switching states. It is engineered specifically for system compatibility within large-scale utility and turbine control frameworks, providing robust physical separation between low-voltage microelectronic control loops and high-voltage field execution circuitry.
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model Designation | IS230TRLSH2B |
| System Series | Mark VIe Control System |
| Module Type | Relay Output Terminal Board Module |
| Country of Origin | USA |
| Channel Configuration | Multi-channel dedicated relay outputs |
| Enclosure / Mounting | Panel or base assembly carrier layout |
| Operating Temperature | 0 degC to +60 degC |
| Storage Temperature | -40 degC to +85 degC |
| Humidity Constraints | 5% to 95% non-condensing relative humidity |
| Terminal Assignment | Function |
|---|---|
| Screw Terminals (Field Side) | Field device loop connections (Form-C or Form-A contacts) |
| I/O Pack Connector | High-density multi-pin communication bridge to the primary controller |
| Shield Terminals | Shield drain wire termination ground points for EMI containment |
Secure the module onto its designated backplate or carrier structure inside the control cabinet. Ensure the mounting fasteners are fully tightened to ground the underlying metal chassis panel and isolate the board from excessive high-frequency structural vibration.
Route all digital signal cables separate from heavy AC power lines to protect against inductive cross-coupling and electrical noise. Terminate field wire shields only at the specified system ground point on the board frame.
When tightening the terminal block screws for field loops, torque them according to standard industrial terminal specifications to prevent loose contact junctions or intermittent continuity dropouts during thermal cycling.
Global Express Shipping
Returns & Warranty
Manufacturer: General Electric
Product No.: IS230TRLSH2B
Country of origin:United States
Product Type: Relay Output Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 2920g
Dimensions: 34cm x 22.5cm x 11.5cm
Shipping port: Xiamen
Warranty: 12 months
