Description

The K 7214 (K7214) is a specialized current distribution board designed for integration within HIQuad X functional infrastructures. This safety-oriented electrical hardware assembly serves to systematically partition central system power feedlines into branch topologies. Functioning within a wide structural voltage flexibility of 24/48 V DC, the unit handles load switching across multiple distributed individual circuits to protect backplane networks and connected industrial control modules. This component acts as a high-capacity current junction platform, streamlining the power architecture inside functional automation panels and safeguarding safety-critical control environments against localized power supply line failures.

Features

• Distributes power safely across multiple independent individual circuits
• Built with a robust current management framework to sustain heavy bulk power loads
• Integrates directly into dedicated HIQuad X system controller cabinets
• High-density design minimizes wiring clutter inside industrial marshalling frameworks

Applications

• System power segmentation within safety automation infrastructures
• Multi-circuit branch load distribution for safety PLC architectures
• Power control marshalling within industrial control panels

Technical Specifications

Installation Guidelines

• Cabinet Frame Grounding: Attach the primary reference chassis grounding strip to the main station protection earth before linking incoming power buses.
• Busbar Connection Integrity: Tighten heavy-gauge supply wire lugs onto the main power distribution input terminals using precise torque specification limits to maintain continuous current loading.
• Branch Wire Separation: Bundle and route individual loop distribution wires systematically away from ambient high-voltage power switchgear lines to minimize noise injection.
