Designed for seamless integration within safety monitoring architectures, the Honeywell 05704-A-0133 serves as a highly configurable Fire Relay Interface Assembly. This module consists of an Expansion Relay Card fitted directly onto a Hex Relay Interface Card, providing comprehensive signaling capabilities for industrial monitoring systems. It acts as a rugged interface between logic controllers and field alarm devices, enabling flexible contact switching across diverse electrical environments.
The Honeywell 05704-A-0133 incorporates multiple relay contact styles to accommodate various load requirements. Users can configure individual relay actions to adapt to specific system demands, selecting between latching or non-latching states as well as normally energised or normally de-energised states. High-quality field terminals facilitate secure termination for heavy-duty field cabling, ensuring long-term operational integrity in critical safety configurations.
| Manufacturer | Honeywell |
| Part Number | 05704-A-0133 |
| Module Type | Fire Relay Interface Assembly |
| Sub-Component Architecture | Expansion Relay Card + Hex Relay Interface Card |
| Relay Contact Configurations | 10 x SPCO, 4 x SPST, 2 x DPCO |
| Selectable Relay Operations | Latching/Non-Latching, Energised/De-Energised |
| Relay Contact Rating (AC) | 5A at 110V/250V AC (non-inductive) |
| Relay Contact Rating (DC) | 5A at 32V DC (non-inductive) |
| Field Terminal Wire Size | 2.5 mm² (14 AWG) |
| Power Consumption (Maximum) | 7W |
| Power Consumption (Typical) | 4W |
| Dimensions (L x W x H) | 12.2 cm x 5.2 cm x 13.2 cm |
| Weight | 0.51 kg |
