Engineered for secure and reliable field termination assembly support within industrial process control environments, the Honeywell 51196094-100 (Model MU-TMCN02) is a heavy-duty mounting channel designed specifically for system cabinets. This structural component features an integrated shield ground bar, which provides a centralized, low-impedance ground connection point for shielded field cables. By facilitating organized wire routing and reliable signal grounding, this FTA mounting channel mitigates electromagnetic interference and helps maintain the integrity of analog and digital signals transmitted to the controller modules.
Typically used within Honeywell TDC 3000 and Experion distributed control system (DCS) enclosures, the MU-TMCN02 simplifies assembly layout, enabling rapid deployment of multiple Field Termination Assemblies (FTAs). Its robust structural profile ensures high mechanical resistance to the vibration and thermal shifts common to industrial control rooms and marshalling cabinets.
| Manufacturer | Honeywell |
| Part Number (SKU) | 51196094-100 |
| Model Code | MU-TMCN02 |
| Component Type | Field Termination Assembly (FTA) Mounting Channel |
| Integrated Grounding | Shield Ground Bar included |
| System Compatibility | Honeywell TDC 3000 / Experion DCS Cabinet Architectures |
| Approximate Shipping Weight | 2.0 kg |
To ensure proper electrical shielding and physical stability, install the MU-TMCN02 channel onto the cabinet structure using the designated mounting hardware. The shield ground bar must be bonded directly to the cabinet’s master instrument ground grid using low-impedance copper grounding straps. Ensure all field cable shields are correctly stripped, clamped, and terminated directly to the grounding bar to prevent ground loops and shield noise coupling.
