Honeywell 51202971-101 Series 8 I/O Link 1 Cable Assembly

SKU 51202971-101

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: 51202971-101
  • Origin United States
  • Product Type: I/O Link Cable Assemblies
  • Payment: T/T, Western Union
  • Weight: 3.5 kg
  • Dimensions: 200 mm x 150 mm x 40 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Cable Assemblies Series 8

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell 51202971-101 Series 8 I/O Link 1 Cable Assembly

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Honeywell 51202971-101 is a Series 8 I/O Link 1 (IOL1) Drop Cable Assembly designed for interconnecting Series 8 Input/Output Termination Assemblies (IOTAs) within Experion LX control system cabinets. Operating as Cable B in a redundant I/O Link configuration, this 51202971-101 multi-drop cable features a gray jacket with green connector labels marked for IOL1B identification. It provides vertical signal and communications distribution across mounting plate columns at a 750 Kbps transfer rate, connecting C300 controllers and Series 8 I/O modules to system header boards and adjacent IOTAs.

Features

  • Redundant Link B Identification: Features a green connector label and IOL1B symbol marking for accurate identification in I/O Link 1 redundant pairs.
  • Multi-Drop Vertical Routing: Engineered with 6 drops at a 6-inch (152 mm) pitch to route vertically within cabinet mounting plates.
  • High-Speed Communication: Supports the standard 750 Kbps Series 8 I/O Link serial communication network.
  • System Integration: Connects C300 controllers, header boards, and various Series 8 IOTAs without exiting the physical enclosure complex.

Applications

  • Honeywell Experion LX Series 8 Control System Cabinets
  • C300 Controller to Series 8 I/O Link 1 (IOL1) interconnection
  • Vertical IOTA signal distribution across cabinet mounting plates

Ordering Information

Part Number Description Cable Type Label Color
51202971-100 Gray Drop Cable, 6 drops, 6-inch (152 mm) pitch, yellow label Cable A Yellow
51202971-101 Gray Drop Cable, 6 drops, 6-inch (152 mm) pitch, green label Cable B Green
51202971-102 Cable pair consisting of one 51202971-100 and one 51202971-101 Cable Pair (A & B) Yellow / Green

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model Number 51202971-101
Product Line Series 8 I/O
Cable Function Series 8 I/O Link 1 (IOL1) Link B Drop Cable
Number of Drops 6 drops
Drop Pitch 6 inches (152 mm)
Cable Color Gray
Connector Label Color Green
IOTA Symbol IOL1B
Baud Rate 750 Kbps

Installation Guidelines

  • Enclosure Boundary: Keep I/O Link cables entirely within the physical confines of the cabinet or cabinet complex; cables must not exit the front, rear, sides, top, or bottom.
  • Channel Placement: Route cable vertically along designated wireways in cabinet mounting plates to connect Series 8 IOTAs.
  • Voltage Separation: Ensure IOTAs associated with field wiring over 30 V are physically separated from IOTAs associated with field wiring under 30 V to minimize electrical interference.
  • Pair Matching: Install alongside the corresponding Cable A assembly (51202971-100) to form a complete redundant I/O Link 1 connection.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the 51202971-101 cable assembly?
The cable assembly serves as the Link B drop cable for Series 8 I/O Link 1, providing multi-drop serial communications between C300 controllers, header boards, and Series 8 IOTAs within a cabinet.
How are Cable A and Cable B distinguished in this Series 8 cable family?
Cable A utilizes a yellow connector label marked for IOL1A, while Cable B utilizes a green connector label marked for IOL1B.
What is the drop spacing and total number of drops on this cable?
The cable assembly features 6 drops spaced at a 6-inch (152 mm) pitch.
Are Series 8 I/O Link cables allowed to extend outside the cabinet?
No, the I/O Link cables must remain entirely within the physical confines of the cabinet complex and are not permitted to exit the enclosure.
