Honeywell

Honeywell 51309223-125 MU-TAMT03 Low Level Analog Input Multiplexer TC FTA

SKU 51309223-125

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: 51309223-125
  • Origin United States
  • Product Type: Analog Input Modules
  • Payment: T/T, Western Union
  • Weight: 3.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Analog Input Modules TDC 3000
Quantità
Call sales Contact

Product Description

Description

The 51309223-125 is a high-performance, low-level analog input multiplexer designed for demanding industrial process control systems. Operating as a Thermocouple Field Termination Assembly (TC FTA), this unit provides high-density signal termination and multiplexing capabilities for temperature measurement applications. It interfaces directly with Honeywell controller architectures, translating microvolt-level signals from field sensors into system-compatible formats.

Engineered for dependability in harsh environments, the MU-TAMT03 accommodates up to 16 low-level analog inputs, specifically optimized for thermocouples and resistance temperature detectors (RTDs). This board features a local Cold Junction Reference (CJR) circuit embedded directly on the termination assembly. This localized CJR ensures highly accurate, localized temperature compensation, preventing thermal gradient errors and maintaining signal integrity from the termination point to the controller interface.

Features

  • Supports up to 16 low-level analog input channels.
  • Integrated Local Cold Junction Reference (CJR) for precise thermocouple temperature compensation.
  • Robust Field Termination Assembly (FTA) design for secure and organized wiring.
  • High noise immunity and signal protection for microvolt-level field signals.
  • Compatible with standard industrial thermocouple and RTD sensor profiles.

Applications

  • Oil and gas refining and petrochemical processing units.
  • Power generation plant thermal monitoring and control.
  • Chemical processing and reactor temperature monitoring.
  • Glass, steel, and high-temperature manufacturing operations.

Technical Specifications

Manufacturer Honeywell
Part Number / Model 51309223-125
Alternate Model Number MU-TAMT03
Product Type Low Level Analog Input Multiplexer TC FTA
Number of Channels 16 Inputs
Cold Junction Reference (CJR) Local CJR
Compatible Sensor Types Thermocouples, RTDs
Shipping Weight 3.0 kg

Installation Guidelines

Proper installation of the 51309223-125 multiplexer ensures safe operation and maximum measurement accuracy. Observe the following engineering guidelines:

  • Mounting: Mount securely within an industrial enclosure or cabinet using standard Honeywell-approved mounting brackets or DIN rail configurations.
  • Wiring: Route sensor signal lines separately from high-voltage AC power lines to avoid electromagnetic interference. Shielded twisted-pair cables are recommended for all low-level thermocouple inputs.
  • Shielding & Grounding: Ensure shield drains are terminated at the designated ground terminals on the FTA to minimize noise pickup.
  • Thermal Management: Keep the area surrounding the local CJR sensor free from direct convective air drafts or heat sources within the cabinet to maintain compensation accuracy.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Honeywell 51309223-125?
The Honeywell 51309223-125 (MU-TAMT03) is a low-level analog input multiplexer Field Termination Assembly (FTA) designed to terminate and multiplex up to 16 thermocouple or RTD sensor signals.
How does local Cold Junction Reference (CJR) benefit temperature measurements?
Local CJR provides temperature compensation directly at the termination board, minimizing measurement errors caused by thermal gradients between the field terminals and the control hardware.
What sensor types are compatible with this multiplexer?
The module is designed to accept low-level analog inputs from thermocouples and compatible RTD temperature sensors.
How many input channels does this FTA support?
This module supports up to 16 input channels.
