900G32-0301

Honeywell

Honeywell 900G32-0301 Digital Input 24 VDC Module

SKU 900G32-0301

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: 900G32-0301
  • Origin United States
  • Product Type: Digital Input Module
  • Payment: T/T, Western Union
  • Weight: 0.175 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Digital Input Modules
Quantità
Call sales Contact

Product Description

The Honeywell 900G32-0301 is a high-density Digital Input Module engineered for the ControlEdge HC900 system, providing 32 sinking input channels. This module is designed to monitor a wide range of 24 Vdc field signals, offering robust performance in harsh industrial environments with an extended operating temperature range. With integrated galvanic isolation split into two groups of 16, this module effectively separates field-side electrical activity from the internal backplane, enhancing system reliability and protecting critical control components from voltage transients.

Features

  • High Channel Density: 32 sinking input channels per module
  • Wide Operating Range: Compatible with signal voltages from 10 Vdc to 32 Vdc
  • Galvanic Isolation: Two isolated groups of 16 inputs for enhanced noise immunity
  • Fast Response: Consistent 5 ms response time for both ON-to-OFF and OFF-to-ON transitions
  • Robust Thermal Specs: Certified for extended operation from -40 degC to 70 degC

Applications

  • Remote monitoring of digital sensors, limit switches, and contact closures
  • High-density I/O acquisition for DCS or PLC architectures
  • Safety-related process interlock monitoring
  • Industrial machinery diagnostic feedback loops

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model 900G32-0301
Product Type Digital Input 24 Vdc Module
Inputs per Module 32 (sinking)
Voltage Range 10 Vdc to 32 Vdc
Galvanic Isolation 2 groups of 16 inputs
ON Voltage Level 9.5 Vdc (min)
OFF Voltage Level 3.5 Vdc (max)
Input Impedance 6.9 K ohms (nominal)
Response Time 5 ms (max)
Operating Temp. -40 to 70 degC
Storage Temp. -40 to 85 degC
Weight 0.175 kg
Shipping Weight 2 kg

Installation Guidelines

  • Module Seating: Insert the module into the HC900 rack carefully to ensure the backplane pins are not bent; ensure the locking mechanism is fully engaged.
  • Sinking Configuration: Ensure field devices are wired for a sinking configuration, where the module provides the ground path for the input signal.
  • Isolation Management: Distribute field wiring to respect the two isolated groups of 16 inputs to maintain the electrical integrity provided by the module design.
  • Environment: The module supports extended operating temperatures; however, ensure adequate airflow within the cabinet to prevent localized hot spots that may exceed the 70 degC limit.
  • Shielding: For inputs routed through long cable runs, utilize shielded twisted-pair cabling and bond the shield to the common ground at the cabinet entry point.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the channel configuration for the 900G32-0301?
This module features 32 sinking digital input channels, organized into two isolated groups of 16.
What voltage range is compatible with these inputs?
The module accepts input signals ranging from 10 Vdc to 32 Vdc.
What are the response times for this module?
The module features a maximum response time of 5 ms for both OFF-to-ON and ON-to-OFF transitions.
Does this module support extended temperature operation?
Yes, it is rated for extended operating temperatures ranging from -40 degC to 70 degC.
