The Honeywell CC-PUIO01 51454205-175 is a Universal Process I/O Module designed for interfacing with analog input, analog output, digital input, and digital output field devices within Experion Series-C I/O systems. Each channel on the module is individually software-configurable to support current-based Analog Input (2, 3, or 4-wire devices), Analog Output, Digital Input, Digital Output, or Pulse Input on channels 15 through 18. Integrated with 16-bit A/D converter resolution and HART 7 protocol support for analog channels, the module executes an input scan rate of 50 ms and includes channel-level electronic short-circuit protection alongside open wire detection capabilities.
| Category | Parameter | Specification |
|---|---|---|
| General Specifications | Manufacturer | Honeywell |
| Module Model Number | CC-PUIO01 | |
| Assembly Part Number | 51454205-175 | |
| Channel Configuration | 32 channels maximum per module | |
| Compatible Non-Redundant IOTA | CC-TUIO01 (12 inch) | |
| Compatible Redundant IOTA | CC-TUIO11 (18 inch) | |
| Analog Input | Input Type | Current (2, 3, or 4 wire devices) |
| Input Range | 0-20 mA or 4-20 mA | |
| A/D Converter Resolution | 16 bit | |
| Input Impedance | 250 Ohm nominal | |
| Input Scan Rate | 50 ms | |
| Hardware Accuracy | 0.1% of full-scale (23.5 +/- 2 degC), 0.17% of full-scale (-40 to 70 degC) | |
| Maximum Input Voltage | +36 VDC to -1.1 VDC (return terminal connected to common) | |
| Normal Mode Rejection Ratio | 12 dB at 60 Hz | |
| Normal Mode Filter Response | Single pole, -3 dB at 16 Hz | |
| Crosstalk | 60 dB (dc to 60 Hz channel-to-channel) | |
| Input Filter | First-order low-pass 16 Hz | |
| Transmitter Power Conditioning | Current limited to 24 mA | |
| Pulse Input | Supported Channels | Channels 15, 16, 17, 18 |
| Frequency Range | 0 to 10 kHz | |
| Minimum Pulse Width | 50 us | |
| Duty Cycle | Any duty cycle meeting minimum pulse width | |
| Environmental | Module Ambient Temperature | -40 to 70 degC |
Global Express Shipping
Returns & Warranty
Manufacturer: Honeywell
Product No.: CC-PUIO01 51454205-175
Country of origin:United States
Product Type: Universal Process I/O Module
Payment: T/T, Western Union
Weight: 450g
Dimensions: 18.0 cm x 12.0 cm x 4.5 cm
Shipping port: Xiamen
Warranty: 12 months
