Honeywell

Honeywell CC-TUIO11 51306852-175 Universal Input Output IOTA Red.

SKU CC-TUIO11

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: CC-TUIO11
  • Origin United States
  • Product Type: Redundant Universal IOTA
  • Payment: T/T, Western Union
  • Weight: 0.85 kg
  • Dimensions: 457 mm x 152 mm x 60 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Experion Series-C Redundant Universal IOTA

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell CC-TUIO11 51306852-175 Universal Input Output IOTA Red.

Download Open in new tab
Quantità
Call sales Contact

Product Description

The Honeywell CC-TUIO11 (Part Number: 51306852-175 ) is a redundant Universal Input Output Termination Assembly (IOTA) designed for the Experion Series-C I/O system. The CC-TUIO11 provides the field wiring termination interface, physical mounting, and signal routing for 32-channel Universal Input Output Modules (IOMs) such as the CC-PUIO01. It enables full I/O redundancy by hosting two IOMs on a single assembly without requiring external cabling or separate redundancy control devices. The assembly distributes 24 VDC bus power to the plugged modules, routes field signals, and supports user-configurable channel operations including analog input, analog output, digital input, and digital output capabilities.

Features

  • Combines I/O module host interfaces and field wiring termination into a single integrated assembly.
  • Direct redundancy support on a single 18-inch IOTA board by accepting dual I/O modules.
  • Two-level detachable terminal block system for field wiring termination.
  • Bussed 24 VDC power connection directly from the IOTA carrier rail.
  • Vertical mounting orientation to accommodate top and bottom enclosure cable entry.
  • Electronic short-circuit protection on channel connections to prevent system damage without inline fuses.
  • Non-incendive field wiring capabilities for hazardous location interfacing.

Applications

  • Experion PKS C300 controller process control system architectures.
  • Redundant universal process I/O termination in industrial cabinets.
  • Mixed analog and digital field instrument interfacing.
  • Centralized process control field wiring marshalling and distribution.

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model CC-TUIO11 (51306852-175)
Product Type Redundant Universal Input Output IOTA
Compatible Module Model CC-PUIO01
Input/Output Channels 32 Channels
Redundancy Support Yes (Redundant configuration)
Nominal Board Size 18 inches (457 mm)
Power Supply Source 24 VDC bus via IOTA carrier
Field Terminal Type Two-level detachable terminals
Terminal Field Wire Size Accepts up to 12 AWG / 2.5 mm stranded wire
Field Power Distribution Integrated on-board distribution via IOTA
Operating Temperature Range -40 to +70 degC (ambient module rating)

Installation Guidelines

  • Mount the IOTA vertically within the enclosure cabinet to facilitate cabinet heat management and top/bottom cable entry.
  • Securely fasten the assembly to the bussed power carrier using the mounting screws to establish the 24 VDC system power connection.
  • Strip field wiring and land conductors into the detachable two-level terminal blocks up to a maximum size of 12 AWG (2.5 mm stranded).
  • Plug two compatible Universal Input Output Modules (CC-PUIO01) onto the IOTA connectors to form a redundant module pair.
  • Ensure proper grounding of the enclosure cabinet and carrier rail according to system guidelines.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the Honeywell CC-TUIO11 used for?
The Honeywell CC-TUIO11 is a redundant Universal Input Output Termination Assembly (IOTA) used to connect 32-channel universal I/O field signals and hold redundant I/O modules in the Experion Series-C system.
Which I/O module is compatible with the CC-TUIO11?
The CC-TUIO11 IOTA is designed to host the Honeywell CC-PUIO01 Universal Input Output module.
Does the CC-TUIO11 support redundant configurations?
Yes. The CC-TUIO11 is an 18-inch redundant IOTA that supports two I/O modules simultaneously on a single assembly without external cabling.
What wire size does the terminal block on the CC-TUIO11 accept?
The detachable field connectors on the CC-TUIO11 accept up to 12 AWG or 2.5 mm stranded wire.
