Processing safety-critical field measurements within the Safety Manager architecture, the Honeywell FC-SAI-1620M executes high-integrity analog signal acquisition for emergency shutdown (ESD) and fire and gas (F&G) systems. This high-density module continuously monitors up to 16 independent analog channels, executing strict onboard diagnostic routines to ensure loop integrity and fault detection. By interfacing directly with safety-critical transmitters, the module provides the fast response times and deterministic performance required to meet stringent safety integrity level requirements in heavy industrial processing environments.
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | FC-SAI-1620M |
| Module Type | Safe High-Density Analog Input Module |
| Number of Channels | 16 Channels |
| Nominal Operating Voltage | 24 Vdc |
| Safety Controller Platform | Honeywell Safety Manager / Safety Manager SC |
| Input Range | 0 to 20 mA or 4 to 20 mA |
| Operating Temperature | 0 to 60 degC |
| Shipping Weight (Calculated) | 3.0 kg (6.6 lbs) |
The FC-SAI-1620M operates within legacy Honeywell Safety Manager configurations and requires alignment with corresponding Field Termination Assemblies (FTAs) such as the TS-SAI-1620. When replacing older revisions of this module, verify that your current Safety Builder software version supports the specific hardware firmware revision of the replacement unit to avoid system load mismatches or diagnostic compile-time warnings.
Operating 16 channels of analog loops simultaneously can generate localized heat buildup inside fully populated enclosures. System designers must maintain adequate ventilation space and ensure that cabinet temperatures remain strictly below 60 degC to prevent premature degradation of the diagnostic circuits. If transmitters are powered externally, the system ground reference must be carefully configured to prevent ground loop noise from corrupting safe signal values.
During commissioning, ensure all unused channels are disabled or configured with appropriate dummy resistors in Safety Builder to suppress open-loop error codes. To maintain high-integrity safety functions, utilize double-shielded twisted pair cables for all analog signal runs and ground the shields exclusively at the designated cabinet grounding bar.
CRITICAL WARNING
This safety module is an integral part of an active protection system. Before inserting, removing, or working on this module, verify that the process loop is in a safe state, the power is fully de-energized, and any accumulated electrostatic charges have been thoroughly bled. Failure to follow safety protocols can lead to spurious trips or unintended system shutdowns.
Shut down the controller rack power or ensure that the designated slot is completely isolated from active hazardous voltages.
Align the module carefully with the chassis card guides to avoid bending the backplane connector pins.
Firmly press the module into the backplane until the extraction levers lock securely into position.
Connect the appropriate pre-wired Field Termination Assembly (FTA) cable and initiate system self-tests through the configuration suite.
Global Express Shipping
Returns & Warranty
Manufacturer: Honeywell
Product No.: FC-SAI-1620M
Country of origin:United States
Product Type: Safety PLC I/O Modules
Payment: T/T, Western Union
Weight: 3000g
Shipping port: Xiamen
Warranty: 12 months
Processing safety-critical field measurements within the Safety Manager architecture, the Honeywell FC-SAI-1620M executes high-integrity analog signal acquisition for emergency shutdown (ESD) and fire and gas (F&G) systems. This high-density module continuously monitors up to 16 independent analog channels, executing strict onboard diagnostic routines to ensure loop integrity and fault detection. By interfacing directly with safety-critical transmitters, the module provides the fast response times and deterministic performance required to meet stringent safety integrity level requirements in heavy industrial processing environments.
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | FC-SAI-1620M |
| Module Type | Safe High-Density Analog Input Module |
| Number of Channels | 16 Channels |
| Nominal Operating Voltage | 24 Vdc |
| Safety Controller Platform | Honeywell Safety Manager / Safety Manager SC |
| Input Range | 0 to 20 mA or 4 to 20 mA |
| Operating Temperature | 0 to 60 degC |
| Shipping Weight (Calculated) | 3.0 kg (6.6 lbs) |
The FC-SAI-1620M operates within legacy Honeywell Safety Manager configurations and requires alignment with corresponding Field Termination Assemblies (FTAs) such as the TS-SAI-1620. When replacing older revisions of this module, verify that your current Safety Builder software version supports the specific hardware firmware revision of the replacement unit to avoid system load mismatches or diagnostic compile-time warnings.
Operating 16 channels of analog loops simultaneously can generate localized heat buildup inside fully populated enclosures. System designers must maintain adequate ventilation space and ensure that cabinet temperatures remain strictly below 60 degC to prevent premature degradation of the diagnostic circuits. If transmitters are powered externally, the system ground reference must be carefully configured to prevent ground loop noise from corrupting safe signal values.
During commissioning, ensure all unused channels are disabled or configured with appropriate dummy resistors in Safety Builder to suppress open-loop error codes. To maintain high-integrity safety functions, utilize double-shielded twisted pair cables for all analog signal runs and ground the shields exclusively at the designated cabinet grounding bar.
CRITICAL WARNING
This safety module is an integral part of an active protection system. Before inserting, removing, or working on this module, verify that the process loop is in a safe state, the power is fully de-energized, and any accumulated electrostatic charges have been thoroughly bled. Failure to follow safety protocols can lead to spurious trips or unintended system shutdowns.
Shut down the controller rack power or ensure that the designated slot is completely isolated from active hazardous voltages.
Align the module carefully with the chassis card guides to avoid bending the backplane connector pins.
Firmly press the module into the backplane until the extraction levers lock securely into position.
Connect the appropriate pre-wired Field Termination Assembly (FTA) cable and initiate system self-tests through the configuration suite.
Global Express Shipping
Returns & Warranty
Orders are processed and delivered Monday-Friday (excluding public holidays).
For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
| Country of origin |
United States
|
