Honeywell FS-FANWR-24R Fan Unit 24 V DC with Readback

SKU FS-FANWR-24R

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Honeywell
Product No.: FS-FANWR-24R
Country of origin:United States
Product Type: Fan Unit
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 150g
Dimensions: 19.0 x 12.0 x 2.0 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Honeywell FS-FANWR-24R is a 24 V DC fan assembly unit equipped with integrated readback functionality, engineered specifically for active thermal management in industrial automation racks, enclosures, and distributed control system architectures. This assembly maintains safe operating temperatures for sensitive electronics by directing forced airflow across critical hardware modules.

The unit features dual high-efficiency cooling fans mounted on a dedicated metal support plate, interfaced via an internal printed circuit board (PCB 07209). External DC power input and fault monitoring signals connect through a standardized 4-pole terminal connector. Built-in electronic monitoring continuously tracks fan rotation speed, driving individual green diagnostic LEDs when normal operating thresholds are met and controlling a potential-free readback relay contact to signal overall operational status to the host control system.

Features

Dual high-efficiency cooling fans with integrated airflow monitoring
Potential-free readback contact closure confirming normal operating RPM of both fans
Independent green status LEDs indicating active operation for each fan
Integrated 2 A slow-blow fuse for internal circuit protection
Protective finger guards installed on both intake and exhaust sides
4-pole plug-in connector for power distribution and status signal wiring

Applications

Thermal management of industrial control system enclosures and rack housings
Forced-air cooling for distributed control system and processor cabinets
Continuous ventilation monitoring in continuous process control rooms
Enclosure heat dissipation for high-density power and I/O assemblies

Technical Specifications

Parameter	Specification
Manufacturer	Honeywell
Product Type	Fan Unit with Readback
Catalog Number	FS-FANWR-24R
Operating Voltage	24 VDC (Range: 12 to 29 VDC)
Power Consumption	9.5 W
Fuse Rating	2 A slow-blow
Readback Contact Rating	Max 300 VDC / 240 VAC at 0.5 A
Wiring Interface	4-pole connector
Country of Origin	United States

FAQ

What is the primary function of the Honeywell FS-FANWR-24R?

The FS-FANWR-24R provides forced-air cooling and thermal management for industrial control system enclosures, utilizing dual fans to prevent overheating of sensitive electronics.

How does the readback function operate on this unit?

A potential-free contact closes when both internal fans maintain proper rotational speed above the minimum threshold, allowing the control system to verify active airflow.

What power supply does the FS-FANWR-24R require?

The unit operates on a nominal 24 VDC power supply, supporting an operating voltage range from 12 to 29 VDC with a total power consumption of 9.5 W.

What safety and protection features are included?

The assembly incorporates physical finger guards on both sides of the fans, an integrated 2 A slow-blow fuse, and built-in diagnostic LEDs for speed verification.
