Honeywell FS-PDB-CPX05 Power Distribution Board

SKU FS-PDB-CPX05

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: FS-PDB-CPX05
  • Origin United States
  • Product Type: Power Distribution Boards
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Dimensions: 190 x 70 x 46 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Power Distribution Boards Safety Systems
Quantità
Call sales Contact

Product Description

Description

Designed for secure power allocation within industrial control cabinets, the Honeywell FS-PDB-CPX05 acts as a robust Power Distribution Board (PDB) engineered for high-availability automation systems. This module facilitates organized, low-loss power distribution from primary power sources to multiple controllers, I/O nodes, and auxiliary field devices.

Constructed to fit standard mounting configurations inside distributed control systems (DCS) and safety system cabinets, the FS-PDB-CPX05 maintains electrical isolation and reliable structural routing, minimizing wiring clutter and ensuring simplified system troubleshooting and maintenance.

Features

  • High-density power distribution layout optimized for critical controller cabinets.
  • Integrated 4-position action pin header connection points for secure, vibration-resistant terminations.
  • Dual DIN rail compatibility supporting both TS32 and TS35 rail profiles.
  • Compact form-factor allowing optimal space utilization within crowded electrical enclosures.
  • Robust physical construction suitable for continuous operation in demanding industrial environments.

Applications

The Honeywell FS-PDB-CPX05 is primarily deployed in safety-instrumented systems (SIS), distributed control systems (DCS), and industrial control cabinets across several sectors:

  • Oil and gas processing facilities
  • Petrochemical and refining plants
  • Power generation and distribution substations
  • Water and wastewater treatment infrastructure

Technical Specifications

Manufacturer Honeywell
Part Number / Model FS-PDB-CPX05
Module Type Power Distribution Board Controller Cabinet
Connector Type 4-position, action pin, header
DIN EN Rails TS32 / TS35 x 7.5
Used Rail Length 191 mm (7.52 in)
Dimensions (L x W x H) 190 x 70 x 46 mm
Shipping Weight 2.0 kg

Installation Guidelines

Proper installation ensures long-term operational reliability and safety within control enclosures:

  • Mounting: Securely snap the module onto a clean, grounded TS32 or TS35 DIN rail. Ensure the minimum required rail length of 191 mm is available to accommodate the module base safely.
  • Wiring: Insert connections into the 4-position action pin header following system-specific wiring diagrams. Verify all contacts are seated fully to prevent high-resistance connection points.
  • Spacing and Ventilation: Maintain standard clearance around the board to allow passive convective cooling and easy access to termination headers.

Compliance and Certifications

  • CE Compliant
  • UL Listed
  • TUV Certified
  • CSA Certified
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
