Honeywell TC-CCR012 Experion C200 Redundant ControlNet Interface Module

SKU TC-CCR012

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Honeywell
Product No.: TC-CCR012
Origin United States
Product Type: ControlNet Interface Modules
Payment: T/T, Western Union
Weight: 1.5 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

To establish reliable, high-integrity communication within distributed control architectures, the Honeywell TC-CCR012 serves as a specialized Redundant Net Interface Module designed for the Experion PKS system family. This module interfaces the C200 controller chassis with redundant ControlNet media links, ensuring uninterrupted communication pathways between controller modules, I/O chassis, and supervisory layers. By continuously monitoring the active communication links, the module provides seamless media failover capabilities to mitigate the risk of single-point network failures in critical industrial processes.

Operating directly within the chassis backplane, the unit routes high-speed control data and diagnostics across dual physical media channels. Its design minimizes power draw from the system backplane while providing robust electrical isolation and noise immunity suitable for harsh industrial environments.

Features

Dual-channel communication interface supporting full ControlNet media redundancy.
Automatic, transparent switchover between Network Channels A and B in the event of media degradation or disconnection.
Direct integration with Honeywell Experion PKS C200 backplanes.
Low power profile to minimize heat dissipation within the control enclosure.
Front-panel status indicators providing immediate diagnostics on module health and active network channels.
Supports hot-swapping under power (within approved non-hazardous or appropriately rated environments).

Applications

Oil and gas refining and upstream production facilities.
Chemical and petrochemical processing plants.
Power generation facilities running Experion C200 system architectures.
Pulp and paper manufacturing lines requiring continuous process uptime.

Technical Specifications

Manufacturer	Honeywell
Model/Part Number	TC-CCR012
Module Type	Redundant Net Interface Module
System Platform	Experion PKS / C200 Controller System
Current Draw @ 5 V DC	1.000 A
Current Draw @ 24 V DC	0.002 A
Interface Ports	Dual BNC Coaxial (Channel A, Channel B)
Mounting Location	Chassis-mounted (Standard I/O or Controller Chassis)
Shipping Weight	1.5 kg

Connections and Interfaces

Port Label	Connection Type	Function
Channel A	BNC Coaxial Connector	Primary ControlNet network trunk connection
Channel B	BNC Coaxial Connector	Secondary (Redundant) ControlNet network trunk connection

Installation Guidelines

Verify that the chassis backplane power is off or follow safety procedures for hot-swap operations in non-hazardous locations.
Align the module with the guide rails of the designated chassis slot and press firmly until the module is fully seated in the backplane connectors.
Secure the module using the integral mounting screws to ensure proper grounding and mechanical stability.
Connect the redundant coaxial network cables to Channel A and Channel B, ensuring BNC connectors are twisted and locked securely.
Confirm that the ControlNet network is properly terminated with matching 75-ohm terminators at both physical ends of the trunk cable.

Compliance and Certifications

CE Compliant
UL Listed
CSA Certified
FM Approved for Class I, Division 2, Groups A, B, C, D Hazardous Locations

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the Honeywell TC-CCR012?

The TC-CCR012 is a Redundant Net Interface Module that connects Experion C200 controllers to dual-channel redundant ControlNet media, ensuring secure and continuous process communication.

What are the electrical power requirements for the TC-CCR012?

The module draws 1.000 A at 5 V DC and 0.002 A at 24 V DC from the backplane.

How does the redundancy switchover work on the TC-CCR012?

The switchover between Channel A and Channel B is fully automatic and transparent. If one channel experiences physical media failure or signal loss, communication seamlessly transitions to the healthy channel without losing control state.

Does this module require external terminators?

Yes. The ControlNet trunk lines connected to the TC-CCR012 via BNC cables must be terminated at both physical ends of the segment using standard 75-ohm terminators.
