Honeywell

Honeywell TK-PRS021 Experion C200 Control Processor Module

SKU TK-PRS021 51404305-375

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: TK-PRS021 51404305-375
  • Origin United States
  • Product Type: Control Processor Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.5 kg
  • Dimensions: 145 mm x 263 mm x 137 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Control Processor Modules Experion PKS

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell TK-PRS021 Experion C200 Control Processor Module

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Honeywell TK-PRS021 is a conformally coated C200 Control Processor Module designed for use within the Experion control system platform. Operating as part of the Chassis Series-A platform, this double slot-width module provides execution of control strategies and connects to various remote I/O modules and networks across the system topology.

The TK-PRS021 control processor supports deployment in both non-redundant and redundant C200E configurations. Power is delivered via the Series-A backplane, with memory retention supported by a built-in lithium battery backup as well as an optional Battery Extension Module (BEM).

Features

  • Double Slot-Width Form Factor: Occupies two chassis slot positions within the Chassis Series-A platform.
  • Conformal Coating: Applied for enhanced environmental protection against corrosive contaminants.
  • Control Processing Capabilities: Executes process control strategies in Experion C200 controller configurations.
  • Redundancy Support: Compatible with Redundancy Modules (TK-PRR021) for redundant control topologies.
  • On-Board Memory Retention: Features an integrated, replaceable lithium battery providing backup power.

Applications

  • Distributed Control Systems (DCS)
  • Process Automation and Control
  • Industrial Continuous and Batch Processing

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model Number TK-PRS021
Product Type Control Processor Module
Chassis Slots Used 2
Supply Voltage 24 V DC
Module Power Requirements +5 V DC +/- 5% @ 1.5 A, +3.3 V DC +/- 5% @ 1.0 A
Module Battery Backup Time Lithium Battery (standard, built in) - 144 hours (non-rechargeable, replaceable) - 6 days
Battery Extension Module (BEM) Backup Battery Extension Module (BEM) - 120 hours (rechargeable) - 5 days
Backplane Current Draw 0.005 A @ 24 VDC, 1.600 A @ 5 VDC, 1.300 A @ 3.3 VDC, 0.007 A @ 1.2 VDC
Operating Temperature 0 to 60 degC
Storage Temperature -40 to 85 degC
Relative Humidity 5 to 95% noncondensing
Conformal Coating Standard (TK prefix)
Weight 0.50 Kg

Installation Guidelines

  • Chassis Slot Allocation: Slide the module into two adjacent slot positions in a compatible Series-A chassis.
  • Power & Removal Limits: Removal and Insertion Under Power (RIUP) is permitted in ordinary, non-hazardous locations. RIUP is strictly NOT permitted when equipment is installed in Class I, Division 2 hazardous locations.
  • Redundant Layouts: In redundant C200 control configurations, two identical chassis setup layouts with matching module slot positions must be maintained. No I/O modules can be inserted into the controller chassis in redundant configurations.
  • Cooling & Spacing: Maintain proper vertical and horizontal clearance around the chassis assembly to allow adequate ventilation.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the chassis slot requirement for the module?
The module occupies two slot positions (double slot-width) in a Chassis Series-A assembly.
What is the standard battery backup time for the device?
The standard built-in non-rechargeable lithium battery provides up to 144 hours (6 days) of backup time.
Can the power supply be extended with a Battery Extension Module?
Yes, using a Battery Extension Module (BEM) provides an additional 120 hours (5 days) of rechargeable backup time.
