The Honeywell 8C-PAONA1 (51454469-175) is a high-precision 16-channel Analog Output (AO) module designed for the Experion PKS Series 8 I/O architecture. As a core component of the C300 control system, this module converts digital control algorithms into accurate 4-20 mA analog signals to drive final control elements such as valve positioners, variable speed drives, and dampers. The 8C-PAONA1 is specifically engineered for high-density deployments, featuring the Series 8 slim vertical form factor that enhances natural convection cooling. This "175" variant comes standard with a factory-applied G3 conformal coating, providing essential protection against corrosive atmospheric contaminants. By ensuring stable signal delivery in harsh industrial environments, the 8C-PAONA1 plays a vital role in maintaining process stability and reducing the total cost of ownership through enhanced hardware durability.
The 8C-PAONA1 (51454469-175) is defined by its ruggedized electronics and seamless integration with the Series 8 I/O Link.
16-Channel Capacity: Supports up to 16 independent analog loops per module, maximizing I/O density within the control cabinet.
Non-HART Signal Path: Dedicated to standard 4-20 mA analog modulation, offering a streamlined and cost-effective solution for control loops that do not require digital HART diagnostics.
G3 Conformal Coating: The 51454469-175 hardware revision is specifically treated to resist corrosion from H2S, Cl2, and ammonia, meeting ISA S71.04 Class G3 standards.
Galvanic Isolation: Provides comprehensive electrical isolation between field wiring and the internal system bus, protecting the C300 controller from field transients and ground loops.
Redundancy Ready: Fully compatible with redundant Series 8 IOTAs, allowing for seamless bumpless transfer in high-availability control applications.
| Attribute | Specification |
| Model | 8C-PAONA1 |
| Part Number | 51454469-175 |
| Brand | Honeywell |
| Series | Experion PKS Series 8 |
| Module Type | Analog Output (Non-HART) |
| Output Range | 4 to 20 mA |
| Number of Channels | 16 |
| Operating Temperature | -40 to 70 Celsius |
| Protection | G3 Conformal Coated |
| Power Consumption | 5.8 Watts Maximum |
| Weight | 0.45 kg |
| Dimensions | 15.20 x 9.80 x 4.20 cm |
Can I replace an 8C-PAONA1 with an 8C-PAOHA1 (HART version)?
Yes, the 8C-PAOHA1 is generally backward compatible and can reside on the same IOTA. However, you must update the module configuration in the Experion Control Builder to enable the HART features.
What does the "Non-HART" designation mean for my field devices?
It means this module only transmits the 4-20 mA analog signal. If you have "Smart" valve positioners, they will still move correctly based on the current, but the DCS will not be able to read digital diagnostic data or valve signatures from them.
How do I verify the G3 coating on this part?
The part number suffix "175" is the primary indicator of the G3 conformal coating. Physically, the board will have a slight uniform sheen compared to non-coated "100" series boards when viewed under reflected light.
Load Impedance Verification: The 8C-PAONA1 is designed to drive loads up to a maximum of 600 Ohms. Before commissioning, calculate the total loop resistance including the field wire run and the positioner impedance. High-resistance loops can cause the output to saturate or trigger "Output Open" alarms.
Hot-Swap Protocol: This module supports Removal and Insertion Under Power (RIUP). In a redundant configuration, ensure the "OK" LED on the partner module is solid green before removing the module being serviced to prevent a process upset.
Wiring and Noise Suppression: To maintain signal integrity, use individual shielded twisted-pair cables for each AO channel. The shields must be terminated at the IOTA's ground bar to prevent electromagnetic interference from inducing "jitter" in the valve control signal.
