Mitsubishi Electric GT2510-VTBA GOT2000 Series Graphic Operation Terminal

SKU GT2510-VTBA

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: GT2510-VTBA
Origin United States
Product Type: Graphic Operation Terminals
Payment: T/T, Western Union
Weight: 2.1 kg
Dimensions: 303 mm x 218 mm x 52 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed to deliver robust visualization and control in demanding industrial environments, the GT2510-VTBA is a high-performance human-machine interface (HMI) belonging to the Mitsubishi Electric GOT2000 Series. This terminal features a high-resolution 10.4-inch TFT color display, providing crisp graphical representations of complex industrial processes. Equipped with an analog resistive touch panel, it ensures precise operator input even when wearing gloves.

The unit is engineered with extensive connectivity options, including built-in Ethernet, RS-232, and RS-422/485 serial ports, enabling seamless integration with PLCs, frequency drives, and other automation controllers. With its generous onboard memory capacity and SD card support, the GT2510-VTBA efficiently handles complex screen designs, data logging, and alarm management recipes. Its IP67F-rated front panel ensures reliable operation in environments exposed to dust, water, and oil mist.

Features

10.4-inch TFT color LCD screen with 65,536 colors for clear, high-contrast visualization.
Analog resistive touch panel supporting precise single-point operator inputs.
Integrated communication interfaces: Ethernet, RS-232, and RS-422/485.
Dual USB ports (USB-A Host and USB Mini-B Device) for high-speed data transfer and programming.
SDHC-compliant memory card slot supporting up to 32GB for data logging and backup.
Robust front-panel protection rated at IP67F, ideal for harsh industrial environments.
Wide-range AC power supply compatibility (100 to 240 VAC).

Applications

Automotive assembly lines and robotic control cells.
Water and wastewater treatment plant monitoring.
Food and beverage processing and packaging machinery.
Oil and gas distribution and monitoring systems.
General factory automation and machine-level visualization.

Technical Specifications

Manufacturer	Mitsubishi Electric
Model / Part Number	GT2510-VTBA
Series	GOT2000 (GT25)
Display Type	TFT color LCD
Screen Size	10.4 inches
Resolution	640 x 480 pixels (VGA)
Display Colors	65,536 colors
Backlight Type	LED (non-replaceable)
Backlight Life	Approx. 60,000 hours or more (at 25 degC ambient)
Touch Panel Type	Analog resistive film
User Memory	32MB (Storage ROM), 80MB (Operation RAM)
Input Voltage	100 to 240 VAC (+10%, -15%)
Frequency	50 / 60 Hz
Operating Temperature	0 to 55 degC
Storage Temperature	-20 to 60 degC
Ambient Humidity	10 to 90% RH (non-condensing)
Protection Rating	Front: IP67F, Inside panel: IP2X
External Dimensions (W x H x D)	303 mm x 218 mm x 52 mm
Panel Cutout Dimensions (W x H)	289 mm x 200 mm
Weight	2.1 kg
Applicable Software	GT Works3 Version 1.112S or later

Connections and Interfaces

Interface Type	Connector Shape / Specification	Function
Ethernet	RJ-45 (10BASE-T/100BASE-TX)	1 channel for network communication and programming
RS-232	D-sub 9-pin (male)	1 channel for serial controller connection (up to 115,200 bps)
RS-422/485	D-sub 9-pin (female)	1 channel for multi-drop serial connection (up to 115,200 bps)
USB Host	USB-A (High-Speed 480 Mbps)	For connecting external storage, keyboards, or mice
USB Device	USB Mini-B (High-Speed 480 Mbps)	Front-facing port for PC transfer and programming
SD Memory Card	SDHC compliant slot	1 channel for data storage and logging (up to 32GB)

Installation Guidelines

Mount the terminal inside a sealed control panel to maintain the IP67F front-panel ingress protection rating.
Ensure the panel cutout dimensions are precisely 289 mm x 200 mm with a panel thickness between 2.0 mm and 4.0 mm.
Maintain a minimum clearance of 100 mm from the top, bottom, and sides of the unit to allow proper self-cooling airflow.
Ground the terminal using a dedicated ground wire with a resistance of 100 Ohms or less, connected to the protective earth terminal.
Avoid installing the unit in direct sunlight, or in areas subject to corrosive gases, greasy fumes, or excessive conductive dust.

Compliance and Certifications

IEC 61131-2
JIS B 3502

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the screen size and resolution of the GT2510-VTBA?

The GT2510-VTBA features a 10.4-inch TFT color LCD screen with a VGA resolution of 640 x 480 pixels.

What programming software is required for this HMI?

The GT2510-VTBA requires GT Works3 Version 1.112S or later for screen design and configuration.

What are the built-in communication interfaces on the GT2510-VTBA?

It includes one Ethernet port (RJ-45), one RS-232 port (D-sub 9-pin male), one RS-422/485 port (D-sub 9-pin female), USB Host (USB-A), USB Device (USB Mini-B), and an SDHC card slot.

What is the power supply requirement for this terminal?

The GT2510-VTBA operates on an AC input voltage range of 100 to 240 VAC at 50/60 Hz.

Does the touch panel support multi-touch gestures?

No, the GT2510-VTBA uses an analog resistive touch panel that supports single-point touch operations only.
