Mitsubishi Electric GT2512-STBA GT25 Series HMI

SKU GT2512-STBA

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: GT2512-STBA
Origin United States
Product Type: Human Machine Interfaces
Payment: T/T, Western Union
Weight: 2.1 kg
Dimensions: 316 mm x 246 mm x 52 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Optimizing operator interaction in complex industrial environments, the GT2512-STBA serves as a high-performance graphical operator terminal within the Mitsubishi Electric GOT2000 platform. This 12.1-inch human-machine interface (HMI) features an SVGA TFT color display designed for clear visualization of machine diagnostics, real-time process monitoring, and control system variables. Equipped with multi-touch and gesture-control capabilities, the unit allows operators to execute intuitive pinch, zoom, and swipe commands directly on the factory floor.

Engineered for seamless integration with MELSEC PLCs and third-party automation controllers, the GT2512-STBA incorporates a robust suite of built-in communication interfaces, including Ethernet, RS-232, and RS-422/485. The hardware architecture supports high-speed data processing, extensive logging capabilities via SD card, and direct peripheral connectivity through USB host and device ports. Its AC-powered design makes it suitable for standard industrial control panels without requiring auxiliary DC power supplies.

Features

High-resolution 12.1-inch TFT color display with 65,536 colors for precise graphical rendering.
Analog resistive touch panel supporting multi-touch gesture operations.
Integrated Ethernet port for network communication, FTP server/client functionality, and remote monitoring.
Dual serial ports (RS-232 and RS-422/485) for legacy controller and drive integration.
SD memory card slot for data logging, project backups, and system firmware updates.
Front-facing USB port for convenient programming and connection to external storage or input devices.
Wide-range AC power input (100-240VAC) accommodating global electrical standards.

Applications

Automotive assembly lines and robotic work cells.
Water and wastewater treatment facility monitoring.
Packaging, labeling, and material handling systems.
Food and beverage processing control stations.
HVAC and building automation supervisory control.

Technical Specifications

Manufacturer	Mitsubishi Electric
Part Number/Model	GT2512-STBA
Series	GOT2000 (GT25)
Display Type	TFT Color LCD
Screen Size	12.1 inch
Resolution	800 x 600 pixels (SVGA)
Display Colors	65,536 colors
Backlight	LED (non-replaceable)
Input Voltage	100 to 240 VAC (+10%, -15%)
Input Frequency	50 / 60 Hz
Power Consumption	41 W or less (under maximum load)
Ethernet Interface	1 channel (100BASE-TX / 10BASE-T)
RS-232 Interface	1 channel (D-sub 9-pin male)
RS-422/485 Interface	1 channel (D-sub 9-pin female)
USB Host	1 channel (USB-A) on rear panel
USB Device	1 channel (USB Mini-B) on front and rear panels
Memory Capacity	32 MB user memory (ROM)
Operating Temperature	0 to 55 degC
Protection Rating	IP67F (front panel when mounted)
Dimensions (W x H x D)	316 mm x 246 mm x 52 mm
Panel Cutout Dimensions	302 mm x 228 mm
Weight	Approx. 2.1 kg

Connections and Interfaces

Interface Port	Connector Type	Function
Ethernet	RJ-45	LAN connection, PLC communication, and FTP services
RS-232	D-sub 9-pin (Male)	Serial connection to controllers, bar code readers, or PCs
RS-422/485	D-sub 9-pin (Female)	Multi-drop serial connection to PLCs and frequency inverters
USB Host	USB Type-A	Data storage transfer and peripheral connection
USB Device	USB Mini-B	Direct PC connection for screen design and programming
SD Card Slot	SD/SDHC Slot	Data logging, recipe storage, and OS installation
Power Input	Screw Terminal Block	AC Power connection (L, N, and Protective Earth)

Installation Guidelines

Panel Mounting: Insert the HMI unit into a panel cutout measuring 302 mm x 228 mm. Secure the unit using the supplied mounting brackets, tightening the screws to the specified torque rating to maintain the IP67F front-panel seal.
Clearance: Maintain a minimum clearance of 100 mm at the top and bottom, and 50 mm on the sides of the unit to ensure adequate natural convection cooling.
Grounding: Connect the functional ground (FG) terminal on the power supply block to a dedicated ground point using a wire with a cross-sectional area of at least 2 mm squared. Ensure grounding resistance is 100 ohms or less.
Wiring: Route communication cables separately from high-voltage power lines and motor drive cables to prevent electromagnetic interference.

Compliance and Certifications

CE Directive (EMC, LVD)
UL / cUL Listed
KC (Korean Certification)

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the screen resolution of the GT2512-STBA?

The GT2512-STBA features a 12.1-inch SVGA TFT color display with a resolution of 800 x 600 pixels.

What power supply voltage does the GT2512-STBA require?

This HMI module operates on an AC power supply input of 100 to 240 VAC.

Does the GT2512-STBA support multi-touch gestures?

Yes, the GT25 Series HMI supports multi-touch and gesture operations such as pinching, zooming, and scrolling.

What is the environmental protection rating of the GT2512-STBA?

The front panel of the GT2512-STBA is rated IP67F when properly mounted in a control panel, providing protection against dust and water ingress.

What communication interfaces are built into the GT2512-STBA?

The unit includes built-in Ethernet, RS-232, RS-422/485, USB Host (Type-A), USB Device (Mini-B), and an SD card slot.
