RD77MS16

Mitsubishi Electric

Mitsubishi Electric RD77MS16 MELSEC iQ-R Series Motion Controller

SKU RD77MS16

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: RD77MS16
  • Origin United States
  • Product Type: Motion Controllers
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

MELSEC iQ-R Series Motion Controllers
Quantità
Call sales Contact

Product Description

Description

Designed for highly precise synchronization and multi-axis coordination, the RD77MS16 motion module operates within the high-performance MELSEC iQ-R Series PLC platform. This module delivers advanced motion control capabilities, facilitating high-speed, noise-immune communication via the SSCNET III/H optical network. Supporting synchronous control, electronic cams, and multi-axis interpolation, it serves as a central controller for complex positioning tasks across industrial automated lines.

The module connects directly to the system backplane, enabling high-speed data exchange with the main CPU. By leveraging optical fiber connections, the RD77MS16 minimizes electromagnetic interference over long distance runs, ensuring signal integrity in demanding industrial environments.

Features

  • Controls up to 16 axes of motion over the SSCNET III/H optical network.
  • Stores up to 600 positioning data points per axis for flexible trajectory planning.
  • Supports multiple control units including pulse, mm, inch, and degree.
  • Features advanced interpolation methods, including 2-axis circular and 2/3/4-axis linear interpolation.
  • Provides optical network synchronization, eliminating cable noise and performance degradation.

Applications

  • High-speed packaging machinery and wrapping systems
  • Multi-axis printing presses and paper converting machinery
  • Semiconductor manufacturing and pick-and-place equipment
  • Material handling, logistics sorting, and gantry robotic systems

Technical Specifications

Manufacturer Mitsubishi Electric
Part Number / Model RD77MS16
Series MELSEC iQ-R Series
Module Type Simple Motion Module
Number of Controlled Axes 16 axes
Positioning Data (per Axis) 600 data points
Control Units pulse, mm, inch, degree
Interpolation Functions 2-axis circular interpolation, 2-axis / 3-axis / 4-axis linear interpolation
Communication Interface SSCNET III/H (Optical Fiber Network)
Shipping Weight 2.0 kg

Connections and Interfaces

Interface Type Function / Description
SSCNET III/H Connectors Optical fiber ports for high-speed communication with servo amplifiers
System Bus Interface Direct backplane connection for power and high-speed CPU synchronization

Installation Guidelines

  • Power off the MELSEC iQ-R base unit completely before inserting or removing the RD77MS16 module.
  • Secure the module using the base unit mounting screw to prevent vibration-induced disconnections.
  • Use only approved SSCNET III/H optical fiber cables. Ensure the cable bending radius conforms to specified optical fiber safety limits to avoid signal attenuation.
  • Maintain adequate clearance around the module vents to ensure convection cooling within the control panel.

Compliance and Certifications

  • CE (EMC Directive)
  • UL / cUL Listed
  • KC (Korean Communications Commission)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How many axes can the RD77MS16 motion controller manage?
The RD77MS16 can control up to 16 axes of motion.
What network interface does the RD77MS16 use to connect with servo drives?
It uses the SSCNET III/H high-speed optical fiber network interface for reliable, noise-immune communication.
What interpolation methods are supported by this module?
The module supports 2-axis circular interpolation as well as 2-axis, 3-axis, and 4-axis linear interpolation.
Can I configure different measurement units for positioning?
Yes, the RD77MS16 supports positioning control units in pulses, mm, inches, and degrees.
