Description

The Omron CP1L-M30DR-A is a high-performing programmable logic controller CPU unit within the CP1L series, engineered to handle sequence logic and process control for small-to-medium industrial machinery. Powered by an AC voltage supply, this micro PLC integrates high-speed processing capabilities with an embedded Ethernet port for direct network communication, remote monitoring, and programming data exchange. The hardware features a built-in block of 30 local digital I/O points, combining discrete DC inputs with electromechanical relay outputs capable of switching diverse load types. It also natively supports multi-axis high-speed counter inputs for rotary encoder feedback and positioning tasks. The unit functions as a central control base and maintains complete compatibility with Omron CP1W series expansion units and option boards to scale hardware configurations based on physical application requirements.

Features

• Embedded Ethernet communication port for peer-to-peer data links and SCADA interface connections.
• 30 built-in digital I/O points providing a flexible layout for localized machine wiring.
• Electromechanical relay outputs allowing direct switching of both AC and DC control circuit loads.
• Integrated high-speed counter inputs for sub-millisecond pulse tracking and encoder interfacing.
• 10K steps internal memory capacity for control program and sequence logic storage.
• Modular scaling through support for standard CP1W series expansion I/O blocks.

Applications

• Commercial building automation, HVAC sequencing, and lighting controls.
• Pumping stations, water treatment systems, and fluid management skids.
• Material handling sorting lines, small conveyors, and lifting stations.
• Packaging machinery, including basic wrapping, sealing, and taping systems.
• Environmental monitoring systems and distributed remote telemetry panels.

Technical Specifications

Performance

Power Requirements

Input/Output

Communication

Installation Guidelines

• DIN Rail Mounting: Clip the controller horizontally onto a standard 35mm DIN rail inside an industrial enclosure. Secure the block using end brackets to prevent horizontal movement under vibration.
• Orientation and Spacing: Mount the device strictly in a horizontal plane. Ensure a minimum clearance distance of 50mm above and below the chassis to enable optimal convection cooling through the ventilation slots.
• AC Power Supply Wiring: Connect the specified AC supply voltage to the dedicated power input terminals. Use appropriate inline fusing to safeguard the internal power stage from line-side electrical surges.
• Cable Routing and Isolation: Maintain strict physical separation between low-voltage DC input cables, Ethernet communication lines, and noisy high-voltage AC output or motor drive lines within the wire ducts.
• Grounding Configuration: Run a dedicated low-impedance ground conductor from the functional ground terminal directly to the main control panel enclosure ground bar.

FAQ

• What type of outputs are built into this specific controller?
• This unit features 12 mechanical relay outputs, providing dry contacts for AC or DC switching.
• What does the 'A' suffix in the model number indicate?
• The 'A' suffix designates that the unit is powered by an alternating current (AC) power supply.
• How many digital I/O points are natively available on the hardware?
• The hardware contains 30 integrated I/O points, consisting of 18 discrete inputs and 12 relay outputs.
• Does this unit require an add-on card for network communication?
• No, this model includes a built-in Ethernet port located directly on the CPU faceplate.
• What is the program execution memory limit for this CPU?
• The CP1L-M series processor offers an internal program capacity of 10K steps.
• Can this controller handle feedback from high-resolution rotary encoders?
• Yes, it features integrated high-speed counter inputs capable of tracking frequencies up to 100 kHz.
• Does this model support pulse outputs for stepper or servo control?
• No, because it uses mechanical relay outputs, it does not support high-speed pulse outputs. For pulse outputs, transistor output models are required.
• How can the onboard I/O count be expanded?
• The I/O density can be increased by attaching standard Omron CP1W series expansion modules.
• What programming environment is used with this hardware?
• The controller is programmed and commissioned using Omron CX-Programmer or Sysmac Studio software.
• Is the program memory retained if the main supply power is lost?
• Yes, the control logic sequence is written to internal non-volatile flash memory, which prevents data loss during a power outage.
