CP2E-N40DR-A

Omron

Omron CP2E-N40DR-A CP2E Series Programmable Controller

SKU CP2E-N40DR-A

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: CP2E-N40DR-A
  • Origin Japan
  • Product Type: Programmable Logic Controllers
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CP2E Series Programmable Logic Controllers
Quantità
Call sales Contact

Product Description

Description

Designed for industrial automation and machinery control, the CP2E-N40DR-A is an Ethernet-capable CPU unit within the Omron CP2E Series. This compact programmable logic controller provides 40 built-in I/O points (24 inputs and 16 outputs) with robust relay outputs, making it highly effective for standard machine control, data collection, and basic IoT monitoring. Equipped with dual built-in Ethernet ports with switching functionality, this controller simplifies network integration, daisy-chaining, and communication with higher-level systems without requiring external switches.

Features

  • Built-in dual Ethernet ports for simplified network architectures and system configuration.
  • Supports up to 40 local digital I/O points (24 inputs and 16 relay outputs) for reliable field connections.
  • Battery-free operation for reduced maintenance overhead and lower operational costs.
  • Robust memory capacity to support extensive programming and variable storage.
  • Provides Modbus TCP and serial gateway capabilities for seamless multi-device communication.
  • Wide AC power supply range of 100 to 240 VAC to accommodate diverse industrial power grids.

Applications

  • Packaging and material handling systems
  • Pumping, water treatment, and fluid control facilities
  • HVAC, climate control, and environmental chamber systems
  • Conveyor systems and assembly lines
  • Automated manufacturing machinery and small-scale assembly systems

Technical Specifications

Manufacturer Omron
Part Number/Model CP2E-N40DR-A
Series CP2E Series (N-Type)
Power Supply Voltage 100 to 240 VAC (50/60 Hz)
Total I/O Points 40 points
Inputs 24 points (24 VDC)
Outputs 16 points (Relay)
Current Consumption (5 VDC) 0.39 A
Current Consumption (24 VDC) 0.09 A
Communication Interfaces 2 x Ethernet ports (built-in switch), expansion option board slots
Operating Temperature -20 to 60 degC
Shipping Weight Approx. 2.0 kg

Installation Guidelines

  • Mounting: Install the controller on a standard DIN rail or use direct screw mounting inside a protective, dust-free enclosure.
  • Thermal Management: Maintain at least 50 mm of clearance above and below the device to ensure adequate natural ventilation.
  • Wiring: Ensure correct AC power connection to the L1 and L2/N terminals. Use appropriate crimp terminals for reliable electrical contact.
  • Grounding: Connect the functional ground terminal to a low-resistance industrial earth ground to minimize electromagnetic interference.

Compliance and Certifications

  • CE Compliant
  • cULus Listed
  • KC (Korea Certification)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the power supply requirement for the Omron CP2E-N40DR-A?
The CP2E-N40DR-A requires an AC power supply input range of 100 to 240 VAC at 50/60 Hz.
How many inputs and outputs are built into the CP2E-N40DR-A?
This PLC has a total of 40 local I/O points, consisting of 24 digital inputs (24 VDC) and 16 digital relay outputs.
Does the CP2E-N40DR-A have built-in network communication?
Yes, it features two built-in Ethernet ports with switching capabilities, allowing for easy daisy-chain networking and connection to higher-level industrial networks.
What is the operating temperature range for this controller?
The CP2E-N40DR-A is rated for operation in temperatures ranging from -20 to 60 degC.
