CQM1-PR001(SAME DAY DELIVERY)

Omron

Omron CQM1-PR001 CQM1 Series Programming Console

SKU CQM1-PR001(SAME DAY DELIVERY)

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: CQM1-PR001(SAME DAY DELIVERY)
  • Origin Japan
  • Product Type: Programming Consoles
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CQM1 Programming Consoles
Quantità
Call sales Contact

Product Description

Description

Designed for direct interfacing with compatible programmable logic controllers, the CQM1-PR001 serves as a handheld programming console for legacy industrial systems. This diagnostic and programming tool enables engineers and maintenance personnel to perform direct code modifications, monitor memory addresses, and execute system troubleshooting at the machine site without requiring a dedicated PC. It connects directly to the peripheral port of the host controller to access internal registers, instruction sets, and program memory.

The unit features an integrated multi-character liquid crystal display (LCD) and a rugged tactile keyboard layout optimized for hex values, addresses, and system commands. Built to withstand industrial environments, this console is an essential tool for maintaining classic Omron control systems, including the CQM1, CS, and CJ series PLCs.

Features

  • Direct, real-time access to PLC program memory and system registers.
  • Clear LCD display showing instructions, addresses, and operand values simultaneously.
  • Tactile keyboard matrix with functional and numerical keys designed for rapid input.
  • Bus-powered operation drawing power directly from the connected PLC host interface.
  • Supports read, write, and force-set/reset operations on various memory areas.

Applications

  • On-site PLC program modifications and debugging.
  • Machine commissioning and manual parameter tuning on the factory floor.
  • Emergency diagnostics and fault clearing where PC access is unavailable or restricted.
  • Direct system status and error code monitoring in legacy control panels.

Technical Specifications

Manufacturer Omron
Model Number CQM1-PR001
Product Type Handheld Programming Console
Compatible Series CQM1 Series, CS1 Series, CJ1 Series
Display Type Liquid Crystal Display (LCD)
Interface Port Peripheral Port Connection
Power Requirements 5V DC (supplied via the host PLC peripheral port)
Keyboard Type Tactile sheet keys

Connections and Interfaces

Interface Element Function
Attached Cable / Connector Connects to the peripheral port of the host PLC for power and serial communication.
LCD Screen Displays memory addresses, operations, and status parameters.
Tactile Keypad Input of commands, numerical values, and program execution control.

Installation Guidelines

  • Always switch off the PLC power supply before connecting or disconnecting the programming console cable.
  • Ensure the communication cable is securely seated to prevent communication interruptions during active editing.
  • Do not operate the programming console in environments with excessive conductive dust, corrosive chemicals, or direct exposure to water.
  • When not in use, store the unit in a clean, dry location to preserve keypad and display responsiveness.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Which PLC models are compatible with the CQM1-PR001?
The CQM1-PR001 is primarily designed for the CQM1 series but can also connect to and program CS-series and CJ-series PLCs using their respective peripheral port connections.
Does the CQM1-PR001 require an external power supply or batteries?
No external power supply or battery is required. The console draws its 5V DC operating power directly from the peripheral port of the connected Omron PLC.
Can I connect the programming console while the PLC is running?
It is highly recommended to turn off the PLC power before connecting or disconnecting the programming console to prevent electrical noise, port damage, or communication disruption.
