D4BL-2DRG

Omron

Omron D4BL-2DRG D4BL Series Guard Lock Safety-Door Switch

SKU D4BL-2DRG

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: D4BL-2DRG
  • Origin Japan
  • Product Type: Safety Switches
  • Payment: T/T, Western Union
  • Weight: 0.8 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

D4BL Safety Switches
Quantità
Call sales Contact

Product Description

Description

Designed to secure heavy-duty machinery safeguarding systems, the D4BL-2DRG heavy-duty guard lock safety-door switch provides mechanical locking and solenoid release to protect personnel from hazardous machine areas. This Type 2 safety switch incorporates a high-durability die-cast aluminum housing, making it highly suitable for demanding industrial automation setups that require strict safety compliance.

Operating with a 24 VDC solenoid lock mechanism, the switch remains securely locked until a release signal is received, preventing accidental entry during dangerous cycles. It is configured with a 2-conduit G1/2 outlet design and a highly adaptable head supporting four distinct mounting orientations, streamlining physical integration on various safety fence profiles.

Features

  • Rugged metal die-cast aluminum housing for harsh industrial environments.
  • Secure solenoid lock with mechanical release function for fail-safe door control.
  • Built-in switch assembly containing 2NC (slow-action) and 1NC (slow-action) contacts.
  • Adjustable head mount allows selection of four different installation directions.
  • IP67 degree of protection against ingress of dust and liquids.
  • Type 2 interlock device classified as low-level coded according to EN ISO 14119.

Applications

  • Automotive manufacturing and assembly lines.
  • Robotic cell enclosures and high-risk work zones.
  • Heavy machining, milling, and metal-stamping equipment guarding.
  • High-inertia industrial machinery that requires delay-to-access control.

Technical Specifications

Manufacturer Omron
Part Number/Model D4BL-2DRG
Series D4BL
Product Type Guard Lock Safety-Door Switch
Lock Method Solenoid lock / Mechanical release
Solenoid Voltage 24 VDC
Interlock Type Type 2 (EN ISO 14119)
Coding Level Low Level coded (EN ISO 14119)
Built-in Contacts 2NC (slow-action) + 1NC (slow-action)
Conduit Outlet G1/2 (2-conduit type)
Head Mounting Direction Four directions possible (ships configured for right-side mounting)
Indicator Type None (without indicator)
Degree of Protection IP67 (EN60947-5-1)
Mechanical Durability 1,000,000 operations minimum
Electrical Durability 500,000 operations minimum (10 A resistive load at 250 VAC)
Operating Speed 0.05 to 0.5 m/s
Operating Frequency 30 operations/minute maximum
Weight 0.8 kg

Installation Guidelines

  • Ensure the operation key is aligned properly with the key slot before securing the main switch body.
  • Do not use the safety switch as a mechanical stop for the door; physical door stoppers must be installed independently.
  • Provide a stable, regulated 24 VDC supply voltage to the solenoid coil to prevent chatter or incomplete unlocking.
  • Mount the switch and its wiring in accordance with EN ISO 14119 specifications to preserve the intended safety integrity level (SIL/PL).

Compliance and Certifications

  • EN ISO 14119
  • EN 60947-5-1
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the locking and unlocking mechanism of the D4BL-2DRG?
The D4BL-2DRG features a solenoid lock and mechanical release. The switch mechanically locks the door when closed, and releases only when the 24 VDC solenoid is energized.
Can the mounting head direction of the switch be adjusted?
Yes, the switch head can be rotated to allow mounting in four different directions. By default, it is shipped with right-side mounting.
What contact configurations are built into this Omron switch?
It features a built-in switch layout of 2NC (slow-action) plus 1NC (slow-action) contacts, dedicated to door status detection and lock monitoring.
What is the environmental protection rating of the D4BL-2DRG?
The switch has an IP67 degree of protection (conforming to EN60947-5-1), providing reliable protection against dust and liquid ingress in industrial environments.
