Facilitating scalable safety control in industrial automation environments, the Omron G9SX-ADA222-T150-RT serves as an advanced flexible safety unit. This high-performance module provides flexible expansion and precise safety output configurations to secure machinery and manufacturing personnel. It is engineered with a combination of instantaneous and time-delayed solid-state safety outputs, allowing for complex safety logic implementation without the need for a dedicated safety PLC.
The G9SX-ADA222-T150-RT features solid-state outputs using P-channel MOS FET transistors, offering exceptional durability and fast response times. It provides dual-channel safety inputs and supports off-delay configurations up to 150 seconds, making it ideal for systems requiring controlled deceleration or stop sequences before total power isolation. Equipped with screw terminals, this unit ensures secure electrical connections under high-vibration conditions.
| Omron |
| G9SX-ADA222-T150-RT |
| G9SX Series |
| Flexible Safety Unit (Advanced Unit) |
| 24 VDC |
| -15% to 10% of rated supply voltage |
| 4 W max. |
| 20.4 VDC to 26.4 VDC |
| Approx. 2.8 kOhm |
| 2 outputs (P-channel MOS FET) |
| 2 outputs (P-channel MOS FET) |
| 2 outputs (PNP transistor, 100 mA max.) |
| 150 s |
| 1 A DC max. |
| 0.8 A DC max. |
| Screw terminals |
| 10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude) |
| 0.2 kg |
To ensure optimal performance and safety compliance, mount the G9SX-ADA222-T150-RT on a standard 35 mm DIN rail inside an IP54 or higher rated control enclosure. Maintain adequate clearance around the unit's ventilation slots to prevent heat buildup. Always isolate the primary power supply before wiring the screw terminals. Use copper conductors rated for the maximum load currents specified. Connect the safety inputs and outputs in accordance with local safety standards and machinery directives to maintain the required safety integrity level (SIL).
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: G9SX-ADA222-T150-RT
Country of origin:Japan
Product Type: Flexible Safety Units
Payment: T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
