Managing precise thermal profiles in demanding processing environments is the primary function of the Omron E5CC-RX0ASM-000 digital temperature controller. Operating with an ultra-fast 50 ms input sampling period, this instrument executes real-time control loop adjustments to stabilize dynamic systems. It features a high-contrast dual display for clear visibility of Process Value (PV) and Set Value (SV) parameters, making it an essential component for critical industrial machinery. Designed with a shallow housing depth to minimize panel space requirements, this unit handles universal thermal inputs with high accuracy, ensuring reliable operational repeatability.
| Manufacturer | Omron |
|---|---|
| Model / SKU | E5CC-RX0ASM-000 |
| Product Series | E5CC Series |
| Product Type | Digital Temperature Controller |
| Input Sampling Period | 50 ms |
| Thermocouple Accuracy | (plus/minus 0.3% of PV or plus/minus 1 degC, whichever is greater) plus/minus 1 digit max. |
| RTD Input Accuracy | (plus/minus 0.2% of PV or plus/minus 0.8 degC, whichever is greater) plus/minus 1 digit |
| Analog Input Accuracy | plus/minus 0.2% FS plus/minus 1 digit max. |
| Current Transformer (CT) Input Accuracy | plus/minus 5% FS plus/minus 1 digit max. |
| Transfer Output Accuracy | plus/minus 0.3% FS max |
| Remote SP Input Accuracy | plus/minus 0.2% FS plus/minus 1 digit max |
| Net Weight | 0.13 kg |
| Shipping Weight (Calculated) | 2.0 kg |
When replacing older legacy controllers such as the Omron E5CN series, verify depth clearances. The E5CC series features a shallow 60 mm body behind the panel, which is significantly smaller than previous configurations. Program parameters can be migrated seamlessly via CX-Thermo software, eliminating the need for manual code translation.
Because of the rapid 50 ms sampling rate, high-gain PID configurations may exhibit oscillations if there is physical thermal lag between the heating element and the sensor probe. Running the auto-tuning sequence at normal system operating temperatures rather than cold-starting the process minimizes integral windup risk.
Thermocouple extension wires must be routed completely isolated from high-voltage AC lines to avoid electromagnetic interference. Ensure that rear terminal connection screws are torqued exactly to manufacturer specifications to maintain solid contact points, as loose connections will induce cold-junction compensation measurement errors.
CRITICAL SAFETY WARNING
Isolate and lock out all electrical power sources supplying the control cabinet prior to beginning hardware installation. Ensure the system has fully discharged any capacitive voltage to prevent electrical shock. Verify physical layout dimensions and panel cutouts prior to securing the controller brackets.
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: E5CC-RX0ASM-000
Country of origin:Japan
Product Type: Digital Temperature Controllers
Payment: T/T, Western Union
Weight: 130g
Shipping port: Xiamen
Warranty: 12 months
