Description

Designed for precise thermal regulation across diverse industrial processes, the Omron E5CN-C2MT-500 AC100-240 digital temperature controller features a compact 1/16 DIN form factor (48 x 48 mm). This high-performance instrument supports multi-input configurations, allowing seamless connection with various thermocouple types to deliver stable closed-loop control. With its integrated current output, the controller regulates heating or cooling elements reliably by modulating control signals. The unit is engineered for easy integration into control panels, providing clear parameter visibility and robust electrical protection.

Features

• Universal input capability supporting multiple thermocouple types (B, E, J, K, L, N, R, S, T, U, W, PLII).
• Linear current output for smooth, continuous modulating control.
• Compact 1/16 DIN enclosure design for standard panel mounting.
• Two auxiliary outputs for alarm and status signaling.
• Equipped with a terminal cover (500-series designation) for enhanced safety and electrical insulation.
• Wide power supply range of 100 to 240 VAC.

Applications

• Packaging machinery and sealing equipment.
• Industrial ovens, furnaces, and heat treatment systems.
• Plastics extrusion and injection molding processes.
• Food and beverage processing lines.
• Semiconductor manufacturing equipment.

Technical Specifications

Installation Guidelines

• Ensure the controller is mounted in a panel with a standard cutout of 45 x 45 mm (1/16 DIN).
• Maintain adequate ventilation clearance around the unit, avoiding installation directly above high heat-generating components.
• Use crimp terminals suitable for M3 screws for wiring connections to ensure secure physical contact.
• Route input signal wiring (thermocouples) away from high-voltage power lines and motor drive cables to prevent electromagnetic interference.
• Ground the panel structure securely according to local electrical codes.

Compliance and Certifications

• CE Marked
• UL Listed
• RoHS Compliant
