The Omron E5CN-HQ2M-500-AC100-240 is a high-performance, high-resolution temperature controller designed for precision industrial process monitoring. Utilizing the advanced architecture of the E5CN-H series, this 1/16 DIN device delivers exceptionally fast processing and high input accuracy. It features universal inputs that allow seamless connection to various sensor types, including thermocouples, platinum resistance thermometers, and analog current/voltage transmitters, minimizing spare parts inventory. With integrated logic operations and predictive maintenance counters, this unit optimizes system reliability and control loop performance in demanding thermal applications.
| Manufacturer | Omron |
| Model / Part Number | E5CN-HQ2M-500-AC100-240 |
| Series | E5CN-H |
| Form Factor | 1/16 DIN (48 x 48 mm) |
| Power Supply Voltage | 100 to 240 VAC, 50/60 Hz |
| Input Types | Universal (Thermocouple, Platinum Resistance Thermometer, Analog Current/Voltage) |
| Sampling Period | 60 ms |
| Indication Accuracy | Thermocouple/Pt: +/-0.1% of PV; Analog Input: +/-0.1% FS |
| Display Resolution | 5 digits (up to 0.01 degC) |
| Panel Depth | 78 mm | Approximately 1.0 kg (including packaging) |
| Operating Temperature | -10 degC to +55 degC (with no icing or condensation) |
| Ambient Operating Humidity | 25% to 85% RH |
To ensure optimal heat dissipation and electrical noise immunity, mount the controller securely into a standard 1/16 DIN panel cutout (45 x 45 mm). Keep the ventilation openings on the top and bottom of the housing clear of obstructions. When wiring the signal inputs, use shielded twisted-pair cables to protect against electromagnetic interference (EMI). Route power cables separately from low-voltage sensor input wiring to prevent noise injection. Ensure the ambient operating temperature remains within the specified -10 degC to +55 degC range.
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: E5CN-HQ2M-500-AC100-240
Country of origin:Japan
Product Type: Temperature Controllers
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
The Omron E5CN-HQ2M-500-AC100-240 is a high-performance, high-resolution temperature controller designed for precision industrial process monitoring. Utilizing the advanced architecture of the E5CN-H series, this 1/16 DIN device delivers exceptionally fast processing and high input accuracy. It features universal inputs that allow seamless connection to various sensor types, including thermocouples, platinum resistance thermometers, and analog current/voltage transmitters, minimizing spare parts inventory. With integrated logic operations and predictive maintenance counters, this unit optimizes system reliability and control loop performance in demanding thermal applications.
| Manufacturer | Omron |
| Model / Part Number | E5CN-HQ2M-500-AC100-240 |
| Series | E5CN-H |
| Form Factor | 1/16 DIN (48 x 48 mm) |
| Power Supply Voltage | 100 to 240 VAC, 50/60 Hz |
| Input Types | Universal (Thermocouple, Platinum Resistance Thermometer, Analog Current/Voltage) |
| Sampling Period | 60 ms |
| Indication Accuracy | Thermocouple/Pt: +/-0.1% of PV; Analog Input: +/-0.1% FS |
| Display Resolution | 5 digits (up to 0.01 degC) |
| Panel Depth | 78 mm | Approximately 1.0 kg (including packaging) |
| Operating Temperature | -10 degC to +55 degC (with no icing or condensation) |
| Ambient Operating Humidity | 25% to 85% RH |
To ensure optimal heat dissipation and electrical noise immunity, mount the controller securely into a standard 1/16 DIN panel cutout (45 x 45 mm). Keep the ventilation openings on the top and bottom of the housing clear of obstructions. When wiring the signal inputs, use shielded twisted-pair cables to protect against electromagnetic interference (EMI). Route power cables separately from low-voltage sensor input wiring to prevent noise injection. Ensure the ambient operating temperature remains within the specified -10 degC to +55 degC range.
Global Express Shipping
Returns & Warranty
Orders are processed and delivered Monday-Friday (excluding public holidays).
For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
| Country of origin |
Japan
|
