Omron H7CC-AWS | Omron | H7CC Digital Preset Counter

SKU H7CC-AWS

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Omron
Product No.: H7CC-AWS
Origin Japan
Product Type: H7CC Digital Counter
Payment: T/T, Western Union
Weight: 1.0 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The H7CC-AWS is a versatile 6-digit digital preset counter from the H7CC series, engineered for high-precision industrial counting and monitoring applications. This standard model features 2-stage settings and is equipped with a high-speed transistor output (DSPT), making it ideal for rapid switching requirements. The device provides exceptional flexibility through its multiple operational configurations, including 1-stage/2-stage preset counter, total/preset counter, batch counter, dual counter, twin counter, and tachometer modes. Designed to operate on a 100 to 240 VAC power supply, the unit utilizes screw terminals for robust, secure electrical integration in automated systems.

Features

Multi-Mode Operation: Supports 7 unique counting and tachometer modes
High-Visibility Display: 6-digit readout for detailed process tracking
Flexible Output: High-speed transistor output (DSPT)
Preset Capability: 2-stage preset setting functionality
Power Supply: Universal 100 to 240 VAC input
Reliable Connection: Standard screw terminals for industrial reliability

Applications

Batch count control on packaging lines
Dual-count tracking for complex machinery
Rotational speed (RPM) and frequency monitoring
Multi-stage sequential production processes
Totalization and output triggering for automated assembly

Technical Specifications

Parameter	Specification
Manufacturer	Omron
Model	H7CC-AWS
Product Type	Preset Counter
Digits	6
Setting Stages	2
Output Type	Transistor (DSPT)
Supply Voltage	100 to 240 VAC
Connection Type	Screw terminals
Weight	Approx. 120 g

Installation Guidelines

Panel Mounting: The unit is designed for standard panel cutout installation. Ensure the gasket is seated correctly to maintain the front-panel seal.
Wiring: Connect power to the AC supply terminals and use shielded cabling for all sensor inputs to prevent noise-induced errors in high-speed counting.
Configuration: Use the front-panel keys to navigate the menu and select the desired operation mode (e.g., Twin Counter or Tachometer) and input preset values before start-up.
Environment: Ensure the ambient temperature and humidity remain within the operating specifications to guarantee the longevity of the electronic components.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What are the available operational modes for the H7CC-AWS?

The H7CC-AWS supports multiple modes, including 1-stage/2-stage preset counter, total/preset counter, batch counter, dual counter, twin counter, and tachometer modes.

Is the H7CC-AWS a 4-digit or 6-digit counter?

The H7CC-AWS is a 6-digit counter.

What type of output does this counter use?

This model features a transistor output (DSPT), which is optimized for high-speed switching applications.
