Omron H5CX-AS-N Digital Timer

SKU H5CX-AS-N

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Omron
Product No.: H5CX-AS-N
Origin Japan
Product Type: Digital Timers
Payment: T/T, Western Union
Weight: 1.0 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The H5CX-AS-N is a high-performance digital timer from Omron’s H5CX-A series. Designed for flexibility and reliability in industrial automation, this standard-type timer features a highly legible, multi-color display (red, green, or orange) and supports a wide variety of timing functions to accommodate complex control sequences.

This model is built with a user-friendly interface that includes DIP switch settings for quick configuration, and it offers both Timer Mode (11 modes) and Twin Timer Mode (4 modes). It is highly versatile in its signal handling, supporting both NPN and PNP inputs as well as gate input, allowing it to be easily integrated into diverse control architectures. It operates on a wide range of power supplies, including 100 to 240 VAC or 24 VAC/12 to 24 VDC, and is designed for secure mounting via a screw terminal block.

Features

Series: H5CX-A Standard type
Operating Modes: 11 Timer modes and 4 Twin Timer modes
Input Flexibility: Supports both NPN and PNP input signals
Display: Multi-color present value display (Red, Green, Orange)
Configuration: Easy setup via physical DIP switches
Power Supply: Wide range (100–240 VAC or 24 VAC/12–24 VDC)
Design: Compact unit with secure screw terminal connections

Applications

Automated assembly line timing sequences
Industrial machine process control
Conveyor system interval management
HVAC system cycling and sequencing
Laboratory equipment and testing procedures

Technical Specifications

Feature	Specification
Manufacturer	Omron
Model	H5CX-AS-N
Series	H5CX-A
Timing Modes	11 Timer / 4 Twin Timer
Input Types	NPN / PNP / Gate
Display Colors	Red, Green, Orange
Supply Voltage	100-240 VAC or 24 VAC/12-24 VDC
Terminal Type	Screw Terminal Block
Weight	0.115 kg

Installation Guidelines

Panel Mounting: Ensure the timer is mounted in a panel cutout with sufficient space for the locking bracket to securely hold the unit against the panel wall.
Wiring Configuration: Use the DIP switches on the side or rear of the unit to define the timer range and operating mode before applying power to the device.
Input Signal Logic: Verify that your system output (NPN or PNP) matches the input wiring configuration of the H5CX-AS-N to ensure proper trigger activation.
Environmental Considerations: Keep the device away from areas with high vibration or excessive electromagnetic noise, as these can interfere with the internal timing circuits.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary difference between Timer Mode and Twin Timer Mode?

Timer Mode is used for standard single-event timing operations, whereas Twin Timer Mode allows for independent control of 'ON' and 'OFF' time intervals.

Can the H5CX-AS-N accept both NPN and PNP signals?

Yes, this model is designed to support both NPN and PNP input signals for flexibility in control circuit design.

What is the benefit of the multi-color display?

The multi-color display (red, green, or orange) allows operators to visually distinguish between different process states or system statuses at a glance.
