Delivering high-performance operation in a compact footprint, the NB5Q-TW01B is a versatile operator interface terminal within the Omron NB Series HMI portfolio. Engineered to streamline human-machine interaction, this unit features a 5.6-inch TFT LCD color display that brings clarity and ease of use to industrial automation tasks. With its rich visual palette of 65,536 colors and long-lasting LED backlighting, operators receive crisp status updates and responsive touch-control functionality. Built-in Ethernet and USB Host connectivity allow this HMI to serve as an efficient hub for program downloads, data-logging, and seamless integration with various PLCs and controllers.
| Manufacturer | Omron |
| Part Number/Model | NB5Q-TW01B |
| Product Series | NB Series |
| Display Type | 5.6-inch TFT LCD Color Touchscreen |
| Resolution (H x V) | 320 x 234 dots |
| Number of Colors | 65,536 |
| Backlight Type | LED |
| Memory Interface | USB Memory / USB Host |
| Line Voltage Range | 20.4 to 27.6 VDC (24 VDC -15% to +15%) |
| Power Consumption | 10 W |
| Battery Lifetime | 5 years typical at 25 degC |
| Dimensions (H x W x D) | 142 mm x 184 mm x 46 mm |
| Weight | 0.62 kg |
Ensure the HMI is mounted securely into a clean, flat panel cutout using the provided mounting clips. Always verify that the front panel rubber gasket is correctly aligned and seated to prevent ingress of dust and moisture. Maintain proper clearance around the rear vents of the enclosure to facilitate heat dissipation, keeping ambient temperatures within standard operating limits. Ground the terminal using the designated functional ground terminal to safeguard against electromagnetic interference.
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: NB5Q-TW01B
Country of origin:Japan
Product Type: Human Machine Interfaces
Payment: T/T, Western Union
Weight: 620g
Dimensions: 142 mm x 184 mm x 46 mm
Shipping port: Xiamen
Warranty: 12 months
