Designed for reliable machine-level interface visualization, the Omron NS10-TV00B-V2 serves as a robust 10.4-inch color touch terminal within the NS-series control ecosystem. This operator interface integrates specialized Ladder Monitor capabilities directly on the screen, enabling maintenance engineers to diagnose PLC programs on-site without needing a dedicated laptop. Built with a heavy-duty black industrial housing, the terminal features a high-clarity TFT LCD display with an integrated LED backlight to maintain high visibility under ambient factory lighting conditions. Operating on standard 24 VDC panel power, it is optimized for high-reliability environments where serial communications or direct bus expansion are preferred over integrated Ethernet paths.
| Manufacturer | Omron |
| Model Number | NS10-TV00B-V2 |
| Product Type | Ladder Monitor / HMI Terminal |
| Display Size | 10.4 inches |
| Display Type | TFT Color LCD |
| Backlight | LED |
| Resolution | 640 x 480 dots |
| Ethernet Port | No |
| Case Color | Black |
| Rated Power Supply | 24 VDC |
| Allowable Voltage Range | 20.4 to 27.6 VDC |
| Power Consumption | 25 W max |
| Net Weight | 2.3 kg |
| Shipping Weight (Calculated) | 8.0 kg (with protective packaging) |
The "-V2" hardware version indicates updated performance standards and enhanced processing over older V1 iterations. It physically swaps directly into existing 10.4-inch cutouts. Note that the non-Ethernet configuration of this SKU means communications are standard RS-232C or RS-422A/485 unless an expansion unit is installed. When replacing an Ethernet-equipped model (like the NS10-TV01B-V2), modify your communication topology within CX-Designer to match the serial port allocation.
Ensure proper ventilation clearance is maintained within the cabinet. Because this device consumes up to 25 W, mounting it near heat-generating hardware such as variable frequency drives or high-current power supplies without proper airflow can result in heat spots on the LCD panel, accelerating LED degradation.
Keep the 24 VDC input lines as short as possible to minimize voltage drops. For optimal noise rejection, use a dedicated Class D ground (grounding resistance of 100 ohms or less) and separate the functional ground (FG) terminal from strong power grounds. Always upload your compiled visualization files via the front-accessible memory card interface or the direct serial connection before securing the final panel enclosure.
CRITICAL WARNING
Isolate and completely shut down all primary AC/DC power sources connected to the enclosure before starting the installation. Confirm that all residual electrical charge has completely dissipated prior to handling any terminals. Incorrect supply voltage wiring can cause catastrophic hardware failure to the HMI motherboard.
Verify that the cabinet panel cutout dimensions correspond exactly with the physical frame dimensions of the NS10 series terminal to ensure the front-facing water-resistant gasket seals correctly.
Insert the HMI unit straight into the cutout, ensuring the integrated waterproof packing ring sits flat against the outer panel sheet.
Secure the device firmly from behind using the provided mounting brackets, tightening them evenly to avoid warping the front bezel or cracking the resistive screen layer.
Wire the power supply terminals to a regulated 24 VDC source and connect the protective ground (GR) terminal directly to your main panel grounding system.
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: NS10-TV00B-V2
Country of origin:Japan
Product Type: HMI Touch Screen Terminals
Payment: T/T, Western Union
Weight: 8000g
Shipping port: Xiamen
Warranty: 12 months
Designed for reliable machine-level interface visualization, the Omron NS10-TV00B-V2 serves as a robust 10.4-inch color touch terminal within the NS-series control ecosystem. This operator interface integrates specialized Ladder Monitor capabilities directly on the screen, enabling maintenance engineers to diagnose PLC programs on-site without needing a dedicated laptop. Built with a heavy-duty black industrial housing, the terminal features a high-clarity TFT LCD display with an integrated LED backlight to maintain high visibility under ambient factory lighting conditions. Operating on standard 24 VDC panel power, it is optimized for high-reliability environments where serial communications or direct bus expansion are preferred over integrated Ethernet paths.
| Manufacturer | Omron |
| Model Number | NS10-TV00B-V2 |
| Product Type | Ladder Monitor / HMI Terminal |
| Display Size | 10.4 inches |
| Display Type | TFT Color LCD |
| Backlight | LED |
| Resolution | 640 x 480 dots |
| Ethernet Port | No |
| Case Color | Black |
| Rated Power Supply | 24 VDC |
| Allowable Voltage Range | 20.4 to 27.6 VDC |
| Power Consumption | 25 W max |
| Net Weight | 2.3 kg |
| Shipping Weight (Calculated) | 8.0 kg (with protective packaging) |
The "-V2" hardware version indicates updated performance standards and enhanced processing over older V1 iterations. It physically swaps directly into existing 10.4-inch cutouts. Note that the non-Ethernet configuration of this SKU means communications are standard RS-232C or RS-422A/485 unless an expansion unit is installed. When replacing an Ethernet-equipped model (like the NS10-TV01B-V2), modify your communication topology within CX-Designer to match the serial port allocation.
Ensure proper ventilation clearance is maintained within the cabinet. Because this device consumes up to 25 W, mounting it near heat-generating hardware such as variable frequency drives or high-current power supplies without proper airflow can result in heat spots on the LCD panel, accelerating LED degradation.
Keep the 24 VDC input lines as short as possible to minimize voltage drops. For optimal noise rejection, use a dedicated Class D ground (grounding resistance of 100 ohms or less) and separate the functional ground (FG) terminal from strong power grounds. Always upload your compiled visualization files via the front-accessible memory card interface or the direct serial connection before securing the final panel enclosure.
CRITICAL WARNING
Isolate and completely shut down all primary AC/DC power sources connected to the enclosure before starting the installation. Confirm that all residual electrical charge has completely dissipated prior to handling any terminals. Incorrect supply voltage wiring can cause catastrophic hardware failure to the HMI motherboard.
Verify that the cabinet panel cutout dimensions correspond exactly with the physical frame dimensions of the NS10 series terminal to ensure the front-facing water-resistant gasket seals correctly.
Insert the HMI unit straight into the cutout, ensuring the integrated waterproof packing ring sits flat against the outer panel sheet.
Secure the device firmly from behind using the provided mounting brackets, tightening them evenly to avoid warping the front bezel or cracking the resistive screen layer.
Wire the power supply terminals to a regulated 24 VDC source and connect the protective ground (GR) terminal directly to your main panel grounding system.
