Description

Engineered for compact machine-level visualization, the NS5-SQ11B-V2 functions as a highly responsive interactive display panel within the Omron NS Series HMI portfolio. This robust operator terminal features a 5.7-inch color display, providing clear graphical representation of machine status, alarm logs, and real-time process parameters. Its tactile touch interface allows operators to execute control commands and configure parameters directly on the factory floor.

This terminal integrates seamlessly into PLC-based automation networks. It is housed in a durable black casing designed to withstand harsh industrial environments, featuring a high level of dust and water protection on the front face. The unit operates on standard industrial DC power, making it a reliable choice for machine builders and system integrators requiring a dependable, space-saving operator interface.

Features

• High-clarity 5.7-inch color display for dynamic industrial process visualization.
• Durable analog resistive touch screen supporting precise, intuitive user operations.
• IP65 and NEMA 4 rated front panel, ensuring reliable protection against water and dust ingress.
• Long-life backup battery supporting memory and system clock retention for up to 5 years.
• Compact design with a space-saving footprint suitable for standard control cabinet doors.

Applications

This interactive terminal is deployed across multiple industries for localized control and monitoring, including:

• Packaging and labeling machinery
• Material handling and conveyor systems
• Special-purpose manufacturing machines
• Food and beverage processing equipment
• Automated assembly systems

Technical Specifications

Installation Guidelines

To ensure proper performance and maintain the IP65 environmental seal, adhere to the following installation protocols:

• Panel Cutout: Prepare the control panel door cutout according to the official Omron dimensions. Ensure the mounting surface is flat and free of burrs.
• Sealing: Verify that the waterproof gasket is properly aligned and undamaged before inserting the terminal into the cutout.
• Mounting Brackets: Tighten the provided mounting brackets evenly to the specified torque. Avoid over-tightening, which may warp the housing.
• Grounding: Connect the functional ground (FG) terminal directly to a dedicated low-impedance ground point (100 ohms or less) using a minimum 2 mm² wire.
• Clearance: Maintain adequate clearance around the unit's rear housing to ensure passive ventilation and prevent heat build-up.
