Description

Designed to facilitate point-to-point serial communication within Sysmac automation architectures, the Omron NX-CIF105 serves as a high-performance serial communications interface unit. Operating within the modular Omron NX-series platform, this module provides a single-channel interface for RS-422A and RS-485 serial communication networks. It supports no-protocol communication, allowing raw data exchange with peripheral industrial devices such as barcode readers, temperature controllers, and measuring instruments.

The unit features robust signal and power isolation to protect the internal PLC backplane from electromagnetic interference and voltage transients common in industrial environments. With its flexible I/O refreshing method (Free-Run refreshing) and configurable Process Data Object (PDO) data sizes ranging from 4 to 80 bytes, the module integrates seamlessly into distributed control configurations via an EtherCAT Coupler Unit or directly adjacent to an NX-series CPU Unit.

Features

• Single RS-422A/485 communication port supporting versatile network topologies.
• Supports no-protocol communication, enabling direct read/write operations with legacy serial devices.
• Configurable communications methods: half-duplex for two-wire connections and full-duplex for four-wire systems.
• Robust isolation design featuring photocouplers and transformers for power lines, and digital isolators for signal paths.
• Selectable transmission buffering enable/disable settings to optimize throughput and data management.
• Built-in data backup functions to prevent loss of volatile communication configurations.
• Compact 12-mm-wide design that optimizes cabinet space and mounts directly onto a standard 35-mm DIN rail.

Applications

• Interfacing Sysmac automation systems with serial-based HMIs, barcode scanners, and RF readers.
• Integrating temperature controllers, load cells, and variable frequency drives (VFDs) into central control systems.
• Factory automation, material handling, and packaging line distributed control networks.

Technical Specifications

Installation Guidelines

• Ensure the system power supply is completely switched off before mounting or removing the NX-CIF105 module from the DIN rail assembly.
• Connect the unit to the backplane NX bus by sliding the interlocking connectors together until a click is heard.
• Utilize shielded twisted-pair cables for all RS-422A/485 lines to minimize electromagnetic noise and prevent transmission errors over long distances.
• Ensure that terminal block connections are wired correctly according to the pin layout for 2-wire (half-duplex) or 4-wire (full-duplex) configurations.
