Omron NX-EC0132 NX Series Incremental Encoder Input Unit

SKU NX-EC0132

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: NX-EC0132
  • Origin Japan
  • Product Type: Incremental Encoder Input Units
  • Payment: T/T, Western Union
  • Weight: 0.13 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Incremental Encoder Input Units NX Series
Quantità
Call sales Contact

Product Description

Description

High-speed motion control systems require precise feedback, and the NX-EC0132 positioning interface unit delivers high-resolution tracking for incremental encoder inputs. Designed as part of the Omron NX series platform, this single-channel module integrates seamlessly with Sysmac controllers to provide synchronous, real-time position data. By utilizing differential line receiver inputs, the unit guarantees high noise immunity and stable signal processing in demanding industrial environments.

This module features flexible system integration with support for multiple I/O refreshing methods, allowing engineers to prioritize either processing speed or synchronous timing precision. Standardized wiring is simplified via a dual-row screwless push-in clamping terminal block, reducing installation time and eliminating terminal-tightening maintenance requirements.

Features

  • Provides 1 channel for incremental encoder connection.
  • Utilizes a differential line receiver input form to maximize noise immunity on high-speed pulse trains.
  • Supports comprehensive feedback signals including counter Phases A, B, and Z, alongside 3 dedicated external inputs.
  • Offers versatile synchronization options: Free-Run, Synchronous, and Task Period Prioritized refreshing.
  • Equipped with a space-saving 24-point screwless clamping terminal block (divided into two 12-terminal rows) for rapid field termination.

Applications

  • High-speed packaging and labeling machinery
  • Multi-axis positioning systems and servo motor feedback integration
  • Material handling systems requiring precise conveyor tracking
  • Automated assembly systems and robotic cells

Technical Specifications

ManufacturerPart Number / ModelSeriesModule TypeNumber of ChannelsInput FormInput SignalsCounting UnitI/O Refreshing MethodExternal ConnectionsWeight
Omron
NX-EC0132
NX Series Position Interface
Incremental Encoder Input Unit
1 channel
Line receiver input
Counter: Phases A, B, and Z; External Inputs: 3
Pulses
Free-Run refreshing, synchronous I/O refreshing, or task period prioritized refreshing
Screwless clamping terminal block (12 terminals x 2)
130 g max.
