Omron NX-TC3407 NX Series Temperature Control Unit

SKU NX-TC3407

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: NX-TC3407
  • Origin Japan
  • Product Type: Temperature Control Modules
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 24 mm x 100 mm x 80 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

NX Series Temperature Control Modules
Quantità
Call sales Contact

Product Description

Description

Designed for precise thermal management within the Sysmac automation platform, the NX-TC3407 temperature control unit provides multi-channel regulation and high-speed PID control. This module facilitates 4 separate control loops, supporting versatile input configurations including both thermocouple and resistance thermometer (Pt100) sensors. Configured with 8 digital PNP outputs designed for pulse width modulation (PWM) control, it enables direct integration into heat and cool control loops.

Operating directly on the high-speed NX I/O Bus, the module guarantees rapid signal processing with a conversion time of 50 ms per unit. The NX-TC3407 features a space-saving 24 mm form factor and utilizes detachable Push-in Plus terminal blocks to streamline wiring, reduce maintenance down-time, and resist vibration-induced loosening in harsh environments.

Features

  • 4-loop PID control supporting independent heat and cool regulation.
  • Universal inputs compatible with multiple thermocouple types and Pt100/JPt100 RTD sensors.
  • 8 PNP digital outputs designed for PWM control tasks (24 VDC, 21 mA per point).
  • Fast conversion rate of 50 ms per unit for dynamic thermal processes.
  • Vibration-resistant Push-in Plus connection terminals for quick toolless wiring.
  • Compact 24 mm width design for dense DIN rail mounting configurations.
  • Seamless integration with Sysmac Studio software for unified programming and diagnostics.

Applications

  • Packaging machinery heat-sealing bars and shrink tunnels.
  • Plastic injection molding and extrusion barrel zones.
  • Semiconductor manufacturing wafer heating systems.
  • Food processing and baking ovens.

Technical Specifications

ManufacturerPart Number / ModelProduct SeriesModule TypeNumber of Control LoopsTemperature Input TypesNumber of Digital OutputsOutput RatingConversion TimeControl ModesI/O Bus TypeConnection TypeDegree of ProtectionDimensions (W x H x D)Weight
Omron
NX-TC3407
NX Series
Temperature Control Unit (4-Loop Type)
4 loops
Thermocouple (B, C WRe5-26, E, J, JPt100, K, L, N, P PLII, R, S, T, U), Pt100 RTD
8 PNP outputs (PWM compatible)
24 VDC, 21 mA per point
50 ms per unit
Heat or cool control
NX I/O Bus
Push-in Plus terminal block (Detachable, 2 connectors)
IP20
24 mm x 100 mm x 80 mm
140 g

Installation Guidelines

  • Mount the module on a standard 35 mm DIN rail within a clean, dry, IP54-rated control enclosure.
  • Ensure that power to the NX-series I/O system is fully disconnected before inserting or removing the terminal block.
  • Maintain adequate clearance above and below the module to facilitate natural thermal dissipation.
  • Route analog sensor and digital output wiring in separate conduits to prevent electrical noise interference.
