Omron NX-TC3408 NX-series Temperature Control Unit

SKU NX-TC3408

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: NX-TC3408
  • Origin Japan
  • Product Type: Temperature Control Modules
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

NX-series Temperature Control Modules
Quantità
Call sales Contact

Product Description

Description

Precision thermal regulation within high-speed industrial environments is achieved using the Omron NX-TC3408, a multi-channel temperature control module designed for the Sysmac automation platform. Operating on the NX-series I/O system backplane, this unit provides 4 independent control loops with integrated thermocouple and resistance thermometer (RTD) inputs. It leverages 4 high-resolution analog outputs (0 to 20 mA or 4 to 20 mA) to deliver smooth, variable manipulated variable (MV) outputs for precise heat or cool control applications.

The unit features a rapid 50 ms conversion time per unit, ensuring fast response times in dynamic thermal systems. To simplify field installation and reduce panel assembly time, the NX-TC3408 is built with screwless Push-in Plus terminal blocks across two detachable connectors. This allows pre-wiring and simple swap-out maintenance, minimizing system downtime.

Features

  • Four independent control loops for multi-zone thermal management.
  • Universal temperature inputs supporting major thermocouples and Pt100/JPt100 RTDs.
  • Four 14-bit analog current outputs configurable for 4 to 20 mA or 0 to 20 mA operation.
  • Fast conversion rate of 50 ms per unit for high-speed tracking.
  • Dual-zone control capabilities supporting both heating and cooling functions.
  • Push-in Plus terminal connections for reliable, tool-free wiring.
  • Detachable front I/O connector blocks for fast maintenance and installation.
  • Seamless integration into EtherCAT or EtherNet/IP networks via NX-series coupler units.

Applications

  • Plastic extrusion and injection molding machine barrel heating zones.
  • Packaging machines requiring precise heat sealing bar regulation.
  • Industrial ovens, drying chambers, and heat treatment furnaces.
  • Semiconductor manufacturing equipment thermal control.
  • Food processing and pasteurization temperature monitoring.

Technical Specifications

Manufacturer Omron
Model/Part Number NX-TC3408
Series NX-series I/O System
Control Loops 4 loops
Temperature Input Types Thermocouple (B, C (WRe5-26), E, J, K, L, N, P (PLII), R, S, T, U), RTD (Pt100, JPt100)
Analog Outputs 4 current outputs (0 to 20 mA, 4 to 20 mA)
Analog Output Resolution 14-bit (1:10000)
Conversion Time 50 ms/unit
Control Mode Heat or Cool control
I/O Connection Type Push-in Plus terminals
Number of Connectors 2 detachable I/O connectors
Enclosure Rating IP20
Width 24 mm
Height 100 mm
Depth 80 mm
Weight 140 g (unpacked)

Connections and Interfaces

The unit features dual-tiered Push-in Plus terminal blocks. Connections are split across two independent, detachable terminal blocks to organize sensory input and control output wiring safely:

Terminal Section Function Description
Sensor Inputs Dedicated connection points for 4-channel Thermocouple or Pt100/JPt100 RTD leads. Fully isolated input circuits.
Analog Outputs 4-channel current output terminals (0 to 20 mA / 4 to 20 mA) routed to control elements like solid-state relays or modulating valves.
NX Bus Connection Direct backplane interface to adjacent NX-series I/O modules and the bus coupler/controller unit.

Installation Guidelines

  • Mount the module securely onto a standard 35 mm DIN rail within a dust-free, dry control cabinet.
  • Ensure that power to the NX-series bus coupler or controller is switched off before mounting or removing the module.
  • To prevent electromagnetic interference (EMI) on sensitive RTD or thermocouple signals, route temperature sensor lines away from high-voltage motor and drive cabling.
  • Maintain a minimum of 10 mm clearance around the module ventilation paths to prevent heat buildup.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Which temperature sensors are compatible with the Omron NX-TC3408?
The NX-TC3408 supports Pt100 and JPt100 RTDs, as well as several thermocouple types including B, C (WRe5-26), E, J, K, L, N, P (PLII), R, S, T, and U.
What outputs are provided on the NX-TC3408 module?
It provides 4 isolated analog current outputs, configurable for either 0 to 20 mA or 4 to 20 mA control signals, with a 14-bit resolution.
Does this temperature control unit feature heater burnout detection?
No, the NX-TC3408 model does not feature heater burnout detection. For heater burnout detection, refer to other models within the Omron NX-TC series.
Can the terminal blocks be removed for wiring?
Yes, the unit features two detachable Push-in Plus I/O connectors, allowing you to pre-wire or swap modules without disconnecting individual wires.
Reviews

More from this brand

Omron NA5-12W101S-V1 | Omron | NA5-V1 Series HMI
NA5-12W101S-V1Omron NA5-12W101S-V1 | Omron | NA5-V1 Series HMI
Omron XWT-ID16 16-Point Digital Input Expansion Module
XWT-ID16Omron XWT-ID16 16-Point Digital Input Expansion Module
Omron G3PE-225B-3N | Omron | Solid State Contactors for Three-phase Heaters
G3PE-225B-3NOmron G3PE-225B-3N | Omron | Solid State Contactors for Three-phase Heaters
Omron NX-ECC202 | Omron | NX-series EtherCAT Coupler Unit
NX-ECC202Omron NX-ECC202 | Omron | NX-series EtherCAT Coupler Unit

NX-TC3408

Stock & lead time on request

Call
  • NX-TC3408
1 1

Omron NX-TC3408 NX-series Temperature Control Unit

Only 8 item(s) left in stock

  • Manufacturer: Omron

  • Product No.: NX-TC3408

  • Country of origin:Japan

  • Product Type: Temperature Control Modules

  • Payment: T/T, Western Union

  • Weight: 140g

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Precision thermal regulation within high-speed industrial environments is achieved using the Omron NX-TC3408, a multi-channel temperature control module designed for the Sysmac automation platform. Operating on the NX-series I/O system backplane, this unit provides 4 independent control loops with integrated thermocouple and resistance thermometer (RTD) inputs. It leverages 4 high-resolution analog outputs (0 to 20 mA or 4 to 20 mA) to deliver smooth, variable manipulated variable (MV) outputs for precise heat or cool control applications.

The unit features a rapid 50 ms conversion time per unit, ensuring fast response times in dynamic thermal systems. To simplify field installation and reduce panel assembly time, the NX-TC3408 is built with screwless Push-in Plus terminal blocks across two detachable connectors. This allows pre-wiring and simple swap-out maintenance, minimizing system downtime.

Features

  • Four independent control loops for multi-zone thermal management.
  • Universal temperature inputs supporting major thermocouples and Pt100/JPt100 RTDs.
  • Four 14-bit analog current outputs configurable for 4 to 20 mA or 0 to 20 mA operation.
  • Fast conversion rate of 50 ms per unit for high-speed tracking.
  • Dual-zone control capabilities supporting both heating and cooling functions.
  • Push-in Plus terminal connections for reliable, tool-free wiring.
  • Detachable front I/O connector blocks for fast maintenance and installation.
  • Seamless integration into EtherCAT or EtherNet/IP networks via NX-series coupler units.

Applications

  • Plastic extrusion and injection molding machine barrel heating zones.
  • Packaging machines requiring precise heat sealing bar regulation.
  • Industrial ovens, drying chambers, and heat treatment furnaces.
  • Semiconductor manufacturing equipment thermal control.
  • Food processing and pasteurization temperature monitoring.

Technical Specifications

Manufacturer Omron
Model/Part Number NX-TC3408
Series NX-series I/O System
Control Loops 4 loops
Temperature Input Types Thermocouple (B, C (WRe5-26), E, J, K, L, N, P (PLII), R, S, T, U), RTD (Pt100, JPt100)
Analog Outputs 4 current outputs (0 to 20 mA, 4 to 20 mA)
Analog Output Resolution 14-bit (1:10000)
Conversion Time 50 ms/unit
Control Mode Heat or Cool control
I/O Connection Type Push-in Plus terminals
Number of Connectors 2 detachable I/O connectors
Enclosure Rating IP20
Width 24 mm
Height 100 mm
Depth 80 mm
Weight 140 g (unpacked)

Connections and Interfaces

The unit features dual-tiered Push-in Plus terminal blocks. Connections are split across two independent, detachable terminal blocks to organize sensory input and control output wiring safely:

Terminal Section Function Description
Sensor Inputs Dedicated connection points for 4-channel Thermocouple or Pt100/JPt100 RTD leads. Fully isolated input circuits.
Analog Outputs 4-channel current output terminals (0 to 20 mA / 4 to 20 mA) routed to control elements like solid-state relays or modulating valves.
NX Bus Connection Direct backplane interface to adjacent NX-series I/O modules and the bus coupler/controller unit.

Installation Guidelines

  • Mount the module securely onto a standard 35 mm DIN rail within a dust-free, dry control cabinet.
  • Ensure that power to the NX-series bus coupler or controller is switched off before mounting or removing the module.
  • To prevent electromagnetic interference (EMI) on sensitive RTD or thermocouple signals, route temperature sensor lines away from high-voltage motor and drive cabling.
  • Maintain a minimum of 10 mm clearance around the module ventilation paths to prevent heat buildup.
Key Features:
#NX-series #Temperature Control Modules

Which temperature sensors are compatible with the Omron NX-TC3408?
The NX-TC3408 supports Pt100 and JPt100 RTDs, as well as several thermocouple types including B, C (WRe5-26), E, J, K, L, N, P (PLII), R, S, T, and U.

What outputs are provided on the NX-TC3408 module?
It provides 4 isolated analog current outputs, configurable for either 0 to 20 mA or 4 to 20 mA control signals, with a 14-bit resolution.

Does this temperature control unit feature heater burnout detection?
No, the NX-TC3408 model does not feature heater burnout detection. For heater burnout detection, refer to other models within the Omron NX-TC series.

Can the terminal blocks be removed for wiring?
Yes, the unit features two detachable Push-in Plus I/O connectors, allowing you to pre-wire or swap modules without disconnecting individual wires.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .

TECHNICAL SPECIFICATIONS

Country of origin
Japan

Technical knowledge
