NX1P2-1040DT

Omron

Omron NX1P2-1040DT NX1P-Series Machine Controller

SKU NX1P2-1040DT

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: NX1P2-1040DT
  • Origin Japan
  • Product Type: Machine Controllers
  • Payment: T/T, Western Union
  • Weight: 0.66 kg
  • Dimensions: 71 mm x 100 mm x 154 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Machine Controllers NX1P-Series
Quantità
Call sales Contact

Product Description

Description

Engineered for compact machine automation, the NX1P2-1040DT sysmac controller integrates sequence control, motion control, and network connectivity within a single compact unit. This controller manages local execution with a 2 ms primary task cycle time, backed by 1.5 MB of program memory and 2 MB of variables memory. Dual built-in Ethernet ports facilitate seamless connection to industrial networks using EtherCAT and EtherNet/IP. The integrated physical I/O layout consists of 24 digital inputs capable of PNP or NPN configurations, alongside 16 PNP-type digital outputs. Designed for scalable motion tasks, it coordinates up to 2 synchronous axes and up to 4 point-to-point (PTP) axes over EtherCAT, serving as a robust processing core for decentralized machine automation systems.

Features

  • Efficient Task Execution: Direct sequence execution with a fixed 2 ms primary task cycle time.
  • Integrated Industrial Networks: Native support for EtherCAT Master and EtherNet/IP communications through 2 RJ45 physical ports.
  • Synchronized Motion Control: Real-time control for 2 synchronized motion axes and up to 4 positioning (PTP) axes.
  • High-Density Local I/O: Built-in 24 inputs (PNP/NPN responsive) and 16 outputs (PNP current-sourcing).
  • Expandable Interfaces: Supports up to 2 serial option boards for RS-232C, RS-422, or RS-485 legacy system integration.

Applications

  • Packaging and labeling machinery.
  • Pick-and-place automated assembly lines.
  • Conveyor tracking and material handling distribution.
  • Multi-axis positioning control units.

Technical Specifications

ManufacturerPart Number/ModelProduct SeriesPrimary Task Cycle TimeProgram MemoryVariables MemoryMaximum Synchronous AxesMaximum PTP AxesIntegrated Digital InputsIntegrated Digital OutputsCommunication InterfacesEthernet PortsMaximum Serial Option BoardsMaximum Remote I/O NodesReal-Time ClockPower Supply Input VoltageDimensions (W x H x D)Weight
Omron
NX1P2-1040DT
NX1P-Series
2 ms
1.5 MB
2 MB
2
4
24 (PNP/NPN)
16 (PNP)
EtherCAT Master, EtherNet/IP, Ethernet TCP/IP
2
2 (RS-232C, RS-422, RS-485 via optional boards)
16
Yes
20.4 to 28.8 VDC
71 mm x 100 mm x 154 mm
0.66 kg

Installation Guidelines

  • Mounting: Mount horizontally on a 35 mm DIN rail inside a protective industrial enclosure.
  • Cooling Clearance: Maintain at least 30 mm of free space above and below the controller to ensure sufficient natural convection airflow.
  • Power Wiring: Apply a stable 24 VDC external power supply. Use SELV/PELV certified power sources to prevent voltage spikes.
  • Grounding: Connect the functional ground terminal to a dedicated low-impedance ground point (less than 100 ohms).
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How many synchronized axes does the Omron NX1P2-1040DT support?
The NX1P2-1040DT machine controller supports up to 2 synchronous axes and up to 4 point-to-point (PTP) motion axes via its integrated EtherCAT master interface.
What are the on-board digital I/O specifications for this controller?
It features 24 digital inputs configurable as PNP or NPN, and 16 digital outputs configured as PNP (current-sourcing).
What networks can the NX1P2-1040DT connect to directly?
The controller has two built-in Ethernet ports supporting EtherCAT Master, EtherNet/IP, and Ethernet TCP/IP communication protocols.
What is the recommended operating voltage for this machine controller?
The NX1P2-1040DT operates on a nominal DC supply voltage ranging between 20.4 and 28.8 VDC.
