NX1P2-1040DT1

Omron

Omron NX1P2-1040DT1 Sysmac NX1P CPU

SKU NX1P2-1040DT1

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: NX1P2-1040DT1
  • Origin Japan
  • Product Type: Sysmac CPUs
  • Payment: T/T, Western Union
  • Weight: 0.66 kg
  • Dimensions: 14.8 cm x 10.0 cm x 7.1 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Sysmac CPUs Sysmac NX1P
Quantità
Call sales Contact

Product Description

Description

Integrating logic, motion control, and database connectivity into a compact form factor, the Omron NX1P2-1040DT1 serves as a core controller within the Sysmac automation platform. Designed for small-to-medium machine automation, this Sysmac NX1P CPU provides synchronized control of all machine devices, including motion, I/O, safety, and vision. It features built-in dual industrial network ports to enable seamless vertical and horizontal integration across factory environments, ensuring reliable execution of synchronized motion control and high-speed data acquisition.

Features

  • Synchronized control of motion, I/O, and safety networks under a single unified controller.
  • Built-in EtherCAT master port and EtherNet/IP port for high-speed device networks and plant-level communications.
  • Support for up to 4 synchronized motion control axes.
  • Expandable local I/O capacity using NX-series digital, analog, and communication modules.
  • Up to 1.5 MB of program memory and 2 MB of variables memory to accommodate complex logic operations.
  • Secure execution with comprehensive user access management and program copy-protection.

Applications

  • Packaging machinery and labeling systems.
  • Material handling and conveyor sorting networks.
  • Pick-and-place assembly stations.
  • Automated pharmaceutical dispensing and packaging.
  • Food processing manufacturing cells.

Technical Specifications

Manufacturer Omron
Part Number/Model NX1P2-1040DT1
Controller Family Sysmac NX1P Series
Primary Task Cycle Time 2 ms
Program Memory 1.5 MB
Variables Memory 2 MB
Communication Interfaces EtherCAT Master, EtherNet/IP, Ethernet TCP/IP
Supply Voltage 20.4 to 28.8 VDC
Dimensions (W x H x D) 14.8 cm x 10.0 cm x 7.1 cm
Weight 0.66 kg

Connections and Interfaces

Interface Type Function / Description
EtherCAT Port RJ45 connector, functions as Master for servo drives, variable speed drives, and remote I/O terminal couplers.
EtherNet/IP Port RJ45 connector, supports peer-to-peer tag data links, HMI communications, and standard TCP/IP socket connections.
Power Terminals Push-in Plus terminal block for 24 VDC control power input.
Built-in I/O Terminals High-speed solid-state digital inputs and outputs for direct field device connection.

Installation Guidelines

  • Mounting: Mount horizontally on a standard 35 mm DIN rail inside an enclosed electrical cabinet.
  • Ventilation: Ensure at least 30 mm of clearance above and below the module to maintain natural convection airflow.
  • Wiring: Use shielded twisted-pair (STP) Category 5e or higher cables for industrial Ethernet networks to prevent electromagnetic interference.
  • Grounding: Connect the functional ground terminal to a low-impedance ground (100 ohms or less) using a dedicated wire.

Compliance and Certifications

  • CE Compliant
  • cULus Listed
  • KC (Korean Communications Commission)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the EtherCAT port on the NX1P2-1040DT1?
The built-in EtherCAT port functions as a master interface, allowing high-speed, synchronized communication with servo drives, vision systems, and distributed I/O modules.
Does the NX1P2-1040DT1 support expansion modules?
Yes, local expansion is achieved by mounting NX-series I/O modules directly to the right side of the CPU module.
What are the power requirements for this controller?
The module operates on a nominal supply voltage of 24 VDC, with an acceptable operating range of 20.4 to 28.8 VDC.
What software is used to program this Sysmac CPU?
The NX1P2-1040DT1 is programmed, configured, and simulated using Omron's Sysmac Studio software platform.
Reviews

More from this brand

Omron NA5-12W101S-V1 | Omron | NA5-V1 Series HMI
NA5-12W101S-V1Omron NA5-12W101S-V1 | Omron | NA5-V1 Series HMI
Omron XWT-ID16 16-Point Digital Input Expansion Module
XWT-ID16Omron XWT-ID16 16-Point Digital Input Expansion Module
Omron G3PE-225B-3N | Omron | Solid State Contactors for Three-phase Heaters
G3PE-225B-3NOmron G3PE-225B-3N | Omron | Solid State Contactors for Three-phase Heaters
Omron NX-ECC202 | Omron | NX-series EtherCAT Coupler Unit
NX-ECC202Omron NX-ECC202 | Omron | NX-series EtherCAT Coupler Unit

NX1P2-1040DT1

Stock & lead time on request

Call
  • NX1P2-1040DT1
1 1

Omron NX1P2-1040DT1 Sysmac NX1P CPU

Only 5 item(s) left in stock

  • Manufacturer: Omron

  • Product No.: NX1P2-1040DT1

  • Country of origin:Japan

  • Product Type: Sysmac CPUs

  • Payment: T/T, Western Union

  • Weight: 660g

  • Dimensions: 14.8 cm x 10.0 cm x 7.1 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Integrating logic, motion control, and database connectivity into a compact form factor, the Omron NX1P2-1040DT1 serves as a core controller within the Sysmac automation platform. Designed for small-to-medium machine automation, this Sysmac NX1P CPU provides synchronized control of all machine devices, including motion, I/O, safety, and vision. It features built-in dual industrial network ports to enable seamless vertical and horizontal integration across factory environments, ensuring reliable execution of synchronized motion control and high-speed data acquisition.

Features

  • Synchronized control of motion, I/O, and safety networks under a single unified controller.
  • Built-in EtherCAT master port and EtherNet/IP port for high-speed device networks and plant-level communications.
  • Support for up to 4 synchronized motion control axes.
  • Expandable local I/O capacity using NX-series digital, analog, and communication modules.
  • Up to 1.5 MB of program memory and 2 MB of variables memory to accommodate complex logic operations.
  • Secure execution with comprehensive user access management and program copy-protection.

Applications

  • Packaging machinery and labeling systems.
  • Material handling and conveyor sorting networks.
  • Pick-and-place assembly stations.
  • Automated pharmaceutical dispensing and packaging.
  • Food processing manufacturing cells.

Technical Specifications

Manufacturer Omron
Part Number/Model NX1P2-1040DT1
Controller Family Sysmac NX1P Series
Primary Task Cycle Time 2 ms
Program Memory 1.5 MB
Variables Memory 2 MB
Communication Interfaces EtherCAT Master, EtherNet/IP, Ethernet TCP/IP
Supply Voltage 20.4 to 28.8 VDC
Dimensions (W x H x D) 14.8 cm x 10.0 cm x 7.1 cm
Weight 0.66 kg

Connections and Interfaces

Interface Type Function / Description
EtherCAT Port RJ45 connector, functions as Master for servo drives, variable speed drives, and remote I/O terminal couplers.
EtherNet/IP Port RJ45 connector, supports peer-to-peer tag data links, HMI communications, and standard TCP/IP socket connections.
Power Terminals Push-in Plus terminal block for 24 VDC control power input.
Built-in I/O Terminals High-speed solid-state digital inputs and outputs for direct field device connection.

Installation Guidelines

  • Mounting: Mount horizontally on a standard 35 mm DIN rail inside an enclosed electrical cabinet.
  • Ventilation: Ensure at least 30 mm of clearance above and below the module to maintain natural convection airflow.
  • Wiring: Use shielded twisted-pair (STP) Category 5e or higher cables for industrial Ethernet networks to prevent electromagnetic interference.
  • Grounding: Connect the functional ground terminal to a low-impedance ground (100 ohms or less) using a dedicated wire.

Compliance and Certifications

  • CE Compliant
  • cULus Listed
  • KC (Korean Communications Commission)
Key Features:
#Sysmac CPUs #Sysmac NX1P

What is the primary function of the EtherCAT port on the NX1P2-1040DT1?
The built-in EtherCAT port functions as a master interface, allowing high-speed, synchronized communication with servo drives, vision systems, and distributed I/O modules.

Does the NX1P2-1040DT1 support expansion modules?
Yes, local expansion is achieved by mounting NX-series I/O modules directly to the right side of the CPU module.

What are the power requirements for this controller?
The module operates on a nominal supply voltage of 24 VDC, with an acceptable operating range of 20.4 to 28.8 VDC.

What software is used to program this Sysmac CPU?
The NX1P2-1040DT1 is programmed, configured, and simulated using Omron's Sysmac Studio software platform.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
