Description

Designed for highly dynamic and precise motion control, the Omron R88M-1L1K530T-BS2 is an AC servo motor optimized for integration with the 1S servo system. This synchronous motor delivers high torque-to-inertia ratios, making it exceptionally responsive in multi-axis machinery configurations. Equipped with a high-resolution absolute encoder and a built-in holding brake, the motor ensures reliable position retention and system safety under power-loss conditions.

Utilizing a standard 100 mm flange layout, this compact industrial-grade motor operates on a 230 V supply voltage, delivering 1.5 kW of continuous power. Its design simplifies wiring and commissioning through unified power and encoder connection protocols compatible with modern Sysmac automation environments.

Features

• High-Resolution Feedback: Integrated 23-bit absolute encoder provides precise position tracking, eliminating the need for battery-backed reference routines.
• Fail-Safe Holding Brake: Built-in electromagnetic brake secures the load safely when power is interrupted.
• Optimized Construction: Straight shaft configuration with key and tap ensures zero-backlash power transmission in heavy-duty mechanical linkages.
• Thermal Efficiency: Engineered for minimal heat generation during high-frequency start-stop cycles.
• Seamless Integration: Perfect electrical compatibility with Omron 1S Servo Drives for rapid setup and configuration.

Applications

• Packaging, labeling, and wrapping machinery
• High-speed pick-and-place robotic systems
• Automated material handling and sorting systems
• Metal processing and multi-axis CNC machine tools
• Semiconductor fabrication and assembly lines

Technical Specifications

Installation Guidelines

• Mounting: Securely mount the motor flange to a rigid, heat-conductive metallic surface to facilitate auxiliary heat dissipation.
• Shaft Alignment: Ensure precise coaxial alignment between the motor shaft and the driven mechanical system to avoid excessive radial or axial load.
• Wiring Safety: Route power and encoder cables separately from signal lines to prevent electromagnetic interference (EMI). Ensure proper grounding of both motor frame and drive housing.
• Ambient Environment: Install in a dry, dust-free environment with ambient temperatures within the manufacturer's specified operational range. Avoid direct exposure to corrosive gases or cutting fluids.
