Description

The Schneider Electric ATS22D17Q is an Altistart 22 soft starter designed for asynchronous motors, delivering a current rating of 17 A across a voltage range of 230-440 V. Engineered to control motor start-up and reduce mechanical stress, this unit supports motor power ratings from 4 to 15 kW. The Altistart 22 range incorporates robust technology to ensure smooth acceleration and deceleration, minimizing wear and tear on connected mechanical components. Built with dimensions of 33.5 x 22 x 28 cm and a weight of 5.60 kg, it provides a reliable and compact solution for industrial motor control applications.

Features

• Designed for 3-phase asynchronous motors with a 17 A current capacity
• Supports a voltage range of 230-440 V and power ratings between 4 and 15 kW
• Provides smooth acceleration and deceleration to minimize mechanical wear and tear
• Compact dimensions and lightweight construction for straightforward cabinet installation
• Active product phase status within the Altistart 22 product range

Applications

• Centrifugal pumps and booster sets
• Fans and ventilation systems
• Conveyors and material handling equipment
• Compressors and agitators

Technical Specifications

Installation Guidelines

• Mount the soft starter vertically on a flat, stable surface within a suitable electrical enclosure ensuring adequate ventilation clearance.
• Maintain proper spacing above and below the unit to allow for natural convection cooling and prevent thermal overload.
• Connect the power supply and motor cables securely to the appropriate terminals, adhering to local electrical safety standards.
• Ensure proper grounding of the enclosure and the soft starter chassis to mitigate electrical noise and interference.
• Verify all control wiring and settings prior to initial power-up and operational testing.
