Schneider Altistart 48 ATS48C32Y Soft Starter

SKU ATS48C32Y

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATS48C32Y
Origin France
Product Type: Soft starters
Payment: T/T, Western Union
Weight: 20.0 kg
Dimensions: 51cm x 46cm x 43cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ATS48C32Y is a Schneider Electric Altistart 48 soft starter engineered for the controlled acceleration and deceleration of asynchronous motors. Capable of handling a rated current of 302 A, this unit operates across a wide voltage range of 208-690 V and supports motor power ratings between 75 kW and 315 kW. By managing the torque and current during the motor start-up sequence, the ATS48C32Y effectively mitigates mechanical stress on drive trains and reduces voltage dips on the power supply network, enhancing the overall reliability of industrial motor-driven systems.

Features

Compatible with 3-phase asynchronous motors
Rated operational current: 302 A
Wide supply voltage range: 208-690 V
Power range coverage: 75-315 kW
Advanced motor protection and diagnostic monitoring
Smooth torque control for reduced mechanical wear

Applications

Pumping stations
Large-scale ventilation and fan systems
Industrial compressor units
Centrifugal machinery
Conveyor and material handling systems

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Altistart 48
Product Type	Soft starter
Rated Current	302 A
Operating Voltage	208-690 V
Power Rating	75-315 kW
Dimensions	51 x 46 x 43 cm
Weight	20.00 kg
Product Status	Active
Commodity Code	84798997

Installation Guidelines

Mounting: Install the soft starter in a vertical position. Ensure the surrounding environment is free from conductive dust and corrosive gases.
Cooling: Maintain sufficient air clearance above and below the device to allow for natural convection. Do not obstruct the internal cooling channels.
Wiring: Connect the power input and output terminals according to the phase sequence. Use cables appropriately sized for a 302 A load.
Grounding: Secure a solid protective earth connection to the chassis to ensure operator safety and EMC compliance.
Environment: Ensure the installation site remains within the specified ambient temperature limits to prevent premature derating or thermal shutdown.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the ATS48C32Y?

The ATS48C32Y is a soft starter used to manage the start-up and stop sequences of 3-phase asynchronous motors, preventing high-torque transients and electrical surges.

What are the motor power and voltage limits for this unit?

This model supports motor power ratings from 75 kW to 315 kW and operates within a voltage range of 208V to 690V.

What is the rated operational current for the ATS48C32Y?

The device is rated for a continuous operational current of 302 A.

What installation factors are critical for this soft starter?

The unit must be mounted vertically with adequate clearance for cooling airflow to ensure proper heat dissipation and reliable operation.
