Schneider Altivar 12 ATV12P075M3 Variable Frequency Drive

SKU ATV12P075M3

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV12P075M3
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 1.05 kg
Dimensions: 18,7cm x 18,7cm x 11,5cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ATV12P075M3 is a compact variable speed drive from the Altivar 12 series, specifically designed for controlling 3-phase asynchronous motors in simple industrial machines. This model is built for mounting on a base plate and is optimized for 200–240 V, 3-phase supply systems. With a power rating of 0.75 kW (1 hp), it offers precise speed control, energy efficiency, and easy integration through its built-in Modbus communication port, making it an ideal choice for applications like conveyors, pumps, and fans.

Features

0.75 kW (1 hp) motor power rating
200–240 V, 3-phase supply voltage
4.2 A continuous output current
Built-in Modbus communication (RS 485)
Compact, base-plate mounted design
Advanced PID and "catch on the fly" functionality
Sensorless flux vector control for improved torque management

Applications

Material handling (conveyor systems)
Industrial pumps and fans
Small-scale packaging machinery
Automated assembly line components
HVAC and extractor systems

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Altivar 12
Product Type	Variable speed drive
Power Rating	0.75 kW (1 hp)
Supply Voltage	200–240 V (3-phase)
Output Current	4.2 A
Communication	Modbus (RS 485, RJ45)
Enclosure	IP20
Dimensions (mm)	143 x 72 x 102.2
Weight	0.7 kg
Commodity Code	85044095

Installation Guidelines

Mounting: Install vertically (±10°) to ensure optimal cooling. The base plate design allows for cabinet mounting, either individually or side-by-side.
Environment: Designed for indoor use in a clean environment (Pollution Degree 2). Keep ambient temperature between -10 degC and 40 degC for standard operation.
Wiring: Use shielded motor cables to minimize electromagnetic interference. Ensure the drive and motor frames are securely connected to a common system ground.
Cooling: Since this model lacks an internal fan, ensure the installation area provides adequate natural ventilation and heat dissipation.
Safety: Always disconnect power and wait at least 15 minutes for internal capacitors to discharge before servicing the terminal connections.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Does the ATV12P075M3 include an internal cooling fan?

No, this model does not have a built-in fan and relies on natural convection cooling.

What communication protocol is built into this drive?

The drive features an integrated RJ45 port for Modbus serial communication.

What is the rated power of this drive?

The drive is rated for 0.75 kW (1 hp) operation.

Is this drive suitable for 3-phase power?

Yes, it is designed for a 200–240 V, 3-phase supply.
