Description

The ATV71HU55M3 is an Altivar 71 variable speed drive engineered by Schneider Electric for high-performance motor control in complex industrial applications. This advanced frequency converter delivers a rated power output of 5.5 kW (7.5 HP) and operates on a 240V power supply. Designed with an integrated EMC filter and a user-friendly graphic terminal, it provides precise torque and speed regulation for demanding synchronous and asynchronous motors. Typical industrial applications include cranes and hoisting equipment, material handling systems, winding machines, extruders, and heavy-duty industrial process machinery. It is fully compatible with standard Schneider Electric Altivar automation architectures and communication networks.

Features

• Altivar 71 variable speed drive designed for complex industrial motor control tasks
• Rated power output of 5.5 kW (7.5 HP) for 240V electrical systems
• Integrated EMC filter for reduced electromagnetic interference
• Equipped with a graphic terminal for intuitive programming and diagnostics
• Robust control algorithms optimized for high torque accuracy and dynamic response

Applications

• Cranes, hoists, and lifting gear control systems
• Industrial winding and unwinding machinery
• Material handling conveyors and automated transport systems
• Extruders, mixers, and heavy industrial process drives

Technical Specifications

Installation Guidelines

• Mount the variable frequency drive vertically onto a clean, solid, and grounded mounting plate inside the control cabinet.
• Ensure adequate clearance spaces above and below the drive housing to maintain unimpeded cooling airflow and prevent thermal overload.
• Connect the 240V power supply lines, motor cables, and control wiring using shielded cables in accordance with EMC guidelines.
• Verify parameter settings and graphic terminal connections before energizing the drive system.
