Description

The GV2AF01 is a TeSys D connection block engineered by Schneider Electric to provide secure electrical and mechanical linking between GV2ME circuit breakers and LC1K contactors. This specialized wiring accessory ensures reliable power distribution and seamless modular assembly within motor starter combinations. Designed with a compact form factor, it facilitates clean control panel layouts and efficient installation. Typical industrial applications include direct-on-line motor starters, machine tool control panels, and automated production line power circuits. It is fully compatible with standard Schneider Electric TeSys motor control components.

Features

• TeSys D connection block designed for GV2ME and LC1K motor starter assemblies
• Provides secure electrical and mechanical linking between circuit breakers and contactors
• Compact and robust design optimized for control cabinet integration
• Engineered for reliable operational lifespan in frequent switching applications

Applications

• Direct-on-line (DOL) motor starter assemblies
• Industrial machinery control panels and automated production lines
• Power distribution and motor protection circuits

Technical Specifications

Installation Guidelines

• Align the connection block securely between the compatible GV2ME circuit breaker and LC1K contactor terminals according to assembly guidelines.
• Fasten all terminal connections firmly to ensure proper electrical contact and mechanical stability.
• Verify correct alignment and physical clearance before mounting the assembled starter unit onto the standard DIN rail.
• Check control wiring and power paths prior to energizing the motor starter circuit.
