Providing critical storage expansion for legacy industrial controllers, this Schneider Electric TSXMCPC002M PCMCIA card delivers reliable application and data backup capabilities. Engineered specifically for legacy Modicon Premium and Modicon Quantum automation platforms, this memory expansion card ensures system stability and program retention in demanding industrial environments. By combining Flash EPROM and SRAM technologies, it provides a dual-purpose storage architecture designed to preserve both active control logic and dynamic process variables during power cycles.
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model / SKU | TSXMCPC002M |
| Product Range Compatibility | Modicon Premium, Modicon Quantum |
| Memory Type | Flash EPROM / SRAM |
| Application Capacity | 2 MB |
| Data Capacity | 1 MB |
| Form Factor | PCMCIA Card |
| Product Phase | Phase-Out (Legacy Support) |
| Commodity Code | 85389091 |
| Export Control Classification (ECCN) | N |
| Shipping Weight (Calculated) | 0.09 kg |
| Package Dimensions (Calculated) | 13 x 9 x 2.5 cm |
The TSXMCPC002M serves as a direct replacement or upgrade path for lower-capacity memory cards within the Modicon Premium and Quantum families. When migrating from smaller cards, verify that the target CPU firmware supports the expanded 2 MB application and 1 MB data boundaries. Ensure your programming software (such as PL7 Pro or Unity Pro) is configured for the correct memory allocation model before downloading the application file.
Because this card utilizes SRAM for dynamic data storage, continuous data retention during power-off states relies heavily on the health of the backup battery located in either the host CPU or the card itself. If the system is powered down for extended periods with a depleted battery, dynamic variables, registers, and runtime parameters stored in the 1 MB SRAM partition may be lost, while the 2 MB Flash EPROM will safely retain the base application program.
Always inspect the PCMCIA slot on the host CPU for dust or bent pins prior to insertion. When inserting the TSXMCPC002M, ensure the card is aligned straight to prevent pin misalignment. Do not force the card into the slot; it should slide in smoothly and click into place when fully seated.
CRITICAL WARNING
Never insert or remove the memory card while the PLC rack is powered on. Hot-swapping the PCMCIA card can cause immediate CPU faults, permanent memory sector corruption, or physical damage to the card's internal circuitry.
Completely de-energize the PLC rack and verify that all status LEDs on the CPU module are completely off.
Align the TSXMCPC002M card with the guide rails of the designated PCMCIA slot on the controller.
Gently push the card into the slot until the eject button pops out, indicating a secure mechanical and electrical connection.
Restore power to the rack and verify via your programming software that the memory expansion card is recognized and healthy.
Global Express Shipping
Returns & Warranty
Manufacturer: Schneider Electric
Product No.: TSXMCPC002M
Country of origin:France
Product Type: PLC Memory Cards
Payment: T/T, Western Union
Weight: 90g
Dimensions: 13 x 9 x 2.5 cm
Shipping port: Xiamen
Warranty: 12 months
Providing critical storage expansion for legacy industrial controllers, this Schneider Electric TSXMCPC002M PCMCIA card delivers reliable application and data backup capabilities. Engineered specifically for legacy Modicon Premium and Modicon Quantum automation platforms, this memory expansion card ensures system stability and program retention in demanding industrial environments. By combining Flash EPROM and SRAM technologies, it provides a dual-purpose storage architecture designed to preserve both active control logic and dynamic process variables during power cycles.
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model / SKU | TSXMCPC002M |
| Product Range Compatibility | Modicon Premium, Modicon Quantum |
| Memory Type | Flash EPROM / SRAM |
| Application Capacity | 2 MB |
| Data Capacity | 1 MB |
| Form Factor | PCMCIA Card |
| Product Phase | Phase-Out (Legacy Support) |
| Commodity Code | 85389091 |
| Export Control Classification (ECCN) | N |
| Shipping Weight (Calculated) | 0.09 kg |
| Package Dimensions (Calculated) | 13 x 9 x 2.5 cm |
The TSXMCPC002M serves as a direct replacement or upgrade path for lower-capacity memory cards within the Modicon Premium and Quantum families. When migrating from smaller cards, verify that the target CPU firmware supports the expanded 2 MB application and 1 MB data boundaries. Ensure your programming software (such as PL7 Pro or Unity Pro) is configured for the correct memory allocation model before downloading the application file.
Because this card utilizes SRAM for dynamic data storage, continuous data retention during power-off states relies heavily on the health of the backup battery located in either the host CPU or the card itself. If the system is powered down for extended periods with a depleted battery, dynamic variables, registers, and runtime parameters stored in the 1 MB SRAM partition may be lost, while the 2 MB Flash EPROM will safely retain the base application program.
Always inspect the PCMCIA slot on the host CPU for dust or bent pins prior to insertion. When inserting the TSXMCPC002M, ensure the card is aligned straight to prevent pin misalignment. Do not force the card into the slot; it should slide in smoothly and click into place when fully seated.
CRITICAL WARNING
Never insert or remove the memory card while the PLC rack is powered on. Hot-swapping the PCMCIA card can cause immediate CPU faults, permanent memory sector corruption, or physical damage to the card's internal circuitry.
Completely de-energize the PLC rack and verify that all status LEDs on the CPU module are completely off.
Align the TSXMCPC002M card with the guide rails of the designated PCMCIA slot on the controller.
Gently push the card into the slot until the eject button pops out, indicating a secure mechanical and electrical connection.
Restore power to the rack and verify via your programming software that the memory expansion card is recognized and healthy.
