Schneider Electric TSXP57202 Modicon Premium Processor Module

SKU TSXP57202

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: TSXP57202
Origin France
Product Type: Processor Modules
Payment: T/T, Western Union
Weight: 0.61 kg
Dimensions: 18.00 cm x 26.00 cm x 9.50 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Optimized for legacy industrial control architectures, the Schneider Electric TSXP57202 is a double-format processor module designed for the Modicon Premium automation platform. This unit provides reliable execution of complex control loops, sequential logic, and communication tasks across demanding manufacturing environments. Operating within the PL7 programming environment, the TSXP57202 manages discrete and analog I/O configurations while maintaining seamless integration with existing Modicon Premium rack systems and communication networks.

With its robust hardware design, this processor module is engineered to minimize system downtime in continuous process industries. It draws power directly from the backplane, requiring 550 mA at 5 V DC, and features physical diagnostic indicators to assist maintenance teams with real-time status monitoring and fault isolation.

Features

Double-format physical footprint occupying two slots on a standard Modicon Premium rack.
Compatible with PL7 Micro, Junior, and Pro programming software suites.
Integrated diagnostic LEDs for rapid troubleshooting of CPU, I/O, and battery status.
Low power consumption profile drawing 550 mA at 5 V DC from the backplane.
Robust mechanical construction suitable for high-vibration and industrial temperature environments.

Applications

Automated assembly lines and discrete manufacturing systems.
Water and wastewater treatment plant control.
Food and beverage processing and packaging systems.
Material handling and conveyor system synchronization.

Technical Specifications

Manufacturer	Schneider Electric
Part Number/Model	TSXP57202
Series	Modicon Premium
Product Type	Processor Module
Format	Double-format (occupies 2 slots)
Current Consumption	550 mA at 5 V DC
Programming Software	PL7 Micro / Junior / Pro
Product Phase	Phase-Out (Legacy)
Weight	0.61 kg
Dimensions	18.00 cm x 26.00 cm x 9.50 cm
Commodity Code	85371091

Connections and Interfaces

Interface Port	Function
TER Port	8-pin mini-DIN connection for programming terminal or local HMI integration
AUX Port	Auxiliary serial communication channel for peripheral devices

Installation Guidelines

Power Off Requirement: Always isolate the rack power supply before inserting or removing the TSXP57202 processor module to prevent damage to the backplane contacts.
Rack Mounting: Ensure the module is fully seated into the double-slot alignment guides of the Modicon Premium rack before tightening the securing screws.
Thermal Management: Maintain unobstructed airflow around the rack assembly, ensuring ambient operating temperatures do not exceed OEM limits.
Grounding: Verify that the rack chassis is connected to a low-impedance industrial ground point to mitigate electromagnetic interference (EMI).

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What programming software is compatible with the TSXP57202 processor?

The TSXP57202 processor module is programmed using the PL7 software suite, including PL7 Micro, PL7 Junior, and PL7 Pro.

What are the power requirements for the TSXP57202?

The module draws 550 mA of current at 5 V DC directly from the Modicon Premium backplane power supply.

How many slots does the TSXP57202 occupy on the rack?

The TSXP57202 is a double-format module and occupies two physical slots on a standard Modicon Premium rack.

What is the current lifecycle status of this module?

The TSXP57202 is in its phase-out/legacy lifecycle phase, making it primarily available as a high-quality spare part or replacement unit for existing installations.
