Schneider Modicon TSXCDP102 Ribbon Cable

SKU TSXCDP102

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: TSXCDP102
  • Origin France
  • Product Type: Cables
  • Payment: T/T, Western Union
  • Weight: 0.07 kg
  • Dimensions: 20cm x 18cm x 2cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Cables
Quantità
Call sales Contact

Product Description

Description

The TSXCDP102 is a 1-meter Ribbon Cable designed for high-reliability interconnection of I/O modules in industrial automation systems. Featuring standard HE10 connectors, this cable facilitates quick and secure signal transmission between control modules and field devices or terminal blocks. Engineered by Schneider Electric for the Modicon series, the TSXCDP102 ensures robust electrical continuity, making it an essential component for maintaining efficient and organized control cabinet wiring.

Features

  • Compatible with I/O modules utilizing HE10 connectors
  • Length: 1 meter
  • High-quality ribbon cable construction for reliable signal integrity
  • Compact design for organized cable management within control panels
  • Designed for industrial-grade durability

Applications

  • PLC I/O system interconnection
  • Industrial control cabinet wiring
  • Connection between digital/analog I/O modules and terminal blocks
  • Automation infrastructure maintenance and upgrades

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Range Modicon
Product Type Ribbon Cable
Model TSXCDP102
Connector Type HE10
Cable Length 1 m
Commodity Code 85444290
Product Phase Active
Weight 0.07 kg
Dimensions (H x W x D) 20 x 18 x 2 cm

Installation Guidelines

  • Handling: Ensure the cable is not kinked or pinched during installation to maintain the integrity of the internal conductors.
  • Connection: Align the HE10 connector carefully with the module port. Ensure the locking mechanism or friction fit is fully engaged for a secure connection.
  • Routing: Route the cable through wire ducts or along cable trays, keeping it separated from high-voltage power lines to minimize potential electromagnetic interference (EMI).
  • Environment: Use within the temperature and humidity ranges specified for the I/O modules it connects.
  • Safety: Always verify that the I/O module power is off before disconnecting or connecting signal cables to avoid potential short circuits.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the length of the TSXCDP102 cable?
The cable has a length of 1 meter.
What type of connectors does the TSXCDP102 use?
It is equipped with standard HE10 connectors.
What is the primary function of this ribbon cable?
It is used to provide reliable signal interconnection between I/O modules and other field devices or terminal blocks in industrial setups.
Is this product currently in active production?
Yes, the TSXCDP102 is currently an active product.
