Schneider STBXTS1100 Modicon STB 6-pin Removable Connector

SKU STBXTS1100

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: STBXTS1100
  • Origin France
  • Product Type: Removable Terminal Connectors
  • Payment: T/T, Western Union
  • Weight: 0.16 kg
  • Dimensions: 12cm x 10cm x 3,5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Modicon STBs Removable Terminal Connectors
Quantità
Call sales Contact

Product Description

Description

The STBXTS1100 is a 6-pin removable screw terminal connector designed for use with Modicon STB digital I/O modules. This connector facilitates secure and reliable field wiring terminations, allowing for quick installation and maintenance of I/O points. Supplied in a package of 20 pieces, it is a standardized solution for managing electrical connections in distributed I/O architectures.

Features

  • 6-pin configuration for standard digital I/O interface.
  • Removable design allows for rapid module replacement without rewiring.
  • Compatible with the Modicon STB distributed I/O platform.
  • Supplied in a bulk pack of 20 units for scalable project support.
  • Designed for secure, vibration-resistant electrical termination.

Applications

  • Field device wiring in distributed control systems.
  • Digital I/O signal distribution in control cabinets.
  • Maintenance and repair of Modicon STB I/O stations.
  • Industrial automation infrastructure assembly.

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Range Modicon STB
Product Type Removable Connector
Connection Type 6-pin Screw Terminal
Quantity 20 pieces
Weight 0.16 kg
Dimensions 12 x 10 x 3.5 cm
Country of Origin France
Commodity Code 85366990
Lifecycle Status Active

Installation Guidelines

  • Terminal Wiring: Ensure wires are stripped to the appropriate length before insertion into the screw terminals to prevent exposed conductors.
  • Tightening: Secure wires firmly using a calibrated screwdriver; avoid over-tightening to prevent damage to the connector housing or terminal threads.
  • Alignment: Carefully align the STBXTS1100 with the I/O module header before applying pressure to ensure pins are not bent during insertion.
  • Maintenance: Periodic inspection of terminal integrity is recommended in high-vibration industrial environments.
  • Polarity: Verify signal labeling on the I/O module before securing wires to ensure correct terminal mapping.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How many pins does the STBXTS1100 connector have?
The STBXTS1100 is a 6-pin removable connector.
What is the quantity supplied in one package?
Each package contains 20 pieces of the 6-pin connector.
Is this connector compatible with all I/O modules?
It is specifically designed for use with Modicon STB digital I/O modules.
What is the current lifecycle status of this product?
The STBXTS1100 is currently an active product in the Schneider Electric portfolio.
