Description

The CA2DN22 is a control module designed for integration into TeSys D industrial electrical and motor control systems. Manufactured by Schneider Electric, this component functions as a control relay engineered to manage auxiliary switching operations and interlocking circuits within automated manufacturing environments.

The CA2DN22 provides dependable switching performance to support complex control logic and system coordination. Weighing 0.42 kg and built to industrial standards, it facilitates seamless maintenance and expansion of established control panels. As a phase-out lifecycle product, it is deployed primarily to support legacy system upkeep and hardware compatibility requirements.

Features

• Auxiliary control relay design for logic and switching operations
• TeSys D product range compatibility for industrial control panels
• Compact physical form factor with an operating weight of 0.42 kg
• Engineered for high reliability in automated electrical systems
• Designed for phase-out system maintenance and replacement support

Applications

• Motor control center auxiliary switching circuits
• Industrial automation and control panel logic routing
• Interlocking and safety circuit management
• Legacy TeSys D system maintenance and repair

Technical Specifications

Installation Guidelines

• Mount the CA2DN22 securely onto a standard DIN rail or panel backplate within an appropriate industrial enclosure.
• Verify that all control circuit wiring is correctly terminated to the corresponding terminal connections in accordance with system schematics.
• Ensure control supply voltage levels match the operational specifications of the module prior to energizing the circuit.
• Maintain proper separation between low-power control wiring and high-voltage power lines to mitigate electromagnetic interference (EMI).
