Description

The Siemens 6AV2128-3QB06-0AX1 SIMATIC HMI MTP1500 is a modern Human Machine Interface (HMI) device from the SIMATIC Unified Comfort Panel series. Designed for industrial automation, this panel features a 15.6-inch widescreen TFT display capable of rendering 16 million colors, offering responsive touch operation for intuitive user interaction. Its robust design and advanced functionality make it suitable for a wide array of automation tasks, integrating seamlessly into PLC-based control systems.

Equipped with a PROFINET interface and supporting Ethernet router services, the Siemens 6AV2128-3QB06-0AX1 ensures reliable integration into contemporary industrial networks. Configuration is supported starting from WinCC Unified Comfort V16, providing engineers with flexible programming and visualization capabilities. The device operates on a 24V DC rated voltage, with an input range of 19.2V to 28.8V, and features dimmable backlighting with a long Mean Time Between Failures (MTBF).

Features

• 15.6-inch widescreen TFT display with 16 million colors
• Responsive touch operation for intuitive user interaction
• Resolution of 1366 x 768 pixels for clear image quality
• Integrated PROFINET interface for industrial network connectivity
• Supports Ethernet router communication services
• Configurable with WinCC Unified Comfort V16 and higher
• Operates on 24V DC (19.2V to 28.8V input range)
• Dimmable backlighting (10–100%) with 50,000 hours MTBF at 25 degC
• Includes open-source software via enclosed DVD for development flexibility

Applications

• Industrial process visualization and control
• Machine operation and monitoring interfaces
• Data acquisition and display in manufacturing environments
• Integration into PLC-based automation systems
• Supervisory control in various industrial sectors

Technical Specifications

Installation Guidelines

1. Safety First: Ensure all power to the control cabinet or panel is de-energized before beginning installation or wiring.
2. Mounting: Securely mount the HMI panel into the prepared panel cutout, ensuring proper sealing to maintain environmental protection.
3. Power Connection: Connect the 24V DC power supply to the designated terminals. Observe correct polarity. Ensure the supply voltage remains within the specified input range of 19.2V to 28.8V DC.
4. Grounding: Establish a reliable protective earth (PE) connection to the panel's grounding terminal to ensure electrical safety and minimize electromagnetic interference.
5. Network Connection: Connect the PROFINET or Ethernet cables to the respective ports. Use shielded cables for industrial environments to prevent noise interference.
6. Cable Management: Route all cables neatly and securely, separating power cables from signal/communication cables to reduce interference.
7. Initial Power-Up: After all connections are verified, re-energize the power supply. The HMI should power on and initiate its startup sequence.
8. Software Configuration: Use WinCC Unified Comfort V16 or a later version to configure the HMI's applications, displays, and communication settings.
