Siemens 6AV3515-1MA22-1AA0 | Coros HMI | OP15 Series Operator Panel

SKU 6AV3515-1MA22-1AA0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV3515-1MA22-1AA0
Origin Germany
Product Type: Operator Panels
Barcode: 85371091
Payment: T/T, Western Union
Weight: 1.1 kg
Dimensions: 25.40cm x 5.10cm x 17.80cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The 6AV3515-1MA22-1AA0 is a Coros HMI OP15/C2 operator panel designed for machine-level control and process visualization. This interface unit supports flexible display configurations, offering either a 4-line, 20-character-per-line format or an 8-line, 40-character-per-line mode, depending on the application requirements. Equipped with 256 KB of user memory and 8 programmable softkeys, the 6AV3515-1MA22-1AA0 enables operators to manage automation tasks and monitor system status with high efficiency. The panel utilizes multiple communication interfaces, including 2x TTY/V.24 and 1x MPI/PPI/L2-DP, allowing for seamless connectivity within legacy Siemens control architectures. This hardware is categorized as discontinued; for new projects, the manufacturer recommends utilizing the OP17 series.

Features

Dual display mode: 4 lines (20 CPL) or 8 lines (40 CPL)
8 programmable softkeys for intuitive operator input
256 KB integrated user memory for project data
Versatile communication ports: 2x TTY/V.24 and 1x MPI/PPI/L2-DP
Robust industrial design for panel mounting
Compact dimensions suitable for standard control enclosures

Applications

Human-Machine Interface (HMI) for PLC-based automation
Machine status monitoring and alarm management
Parameter entry and process setpoint adjustment
Integration in legacy Siemens S5/S7 control systems
Industrial manufacturing process control

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Product Range	Coros HMI
Subrange	OP15 series
Model	6AV3515-1MA22-1AA0
Display Configuration	4 lines (20 CPL) or 8 lines (40 CPL)
User Memory	256 KB
Softkeys	8
Communication Interfaces	2x TTY/V.24, 1x MPI/PPI/L2-DP
Weight	1.10kg
Dimensions	25.40cm x 5.10cm x 17.80cm
Product Phase	Obsolete
Predecessor	6AV3515-1MA22
Commodity Code	85371091

Installation Guidelines

Panel Mounting: The device is designed for flush mounting in a control panel cutout. Ensure the gasket is properly seated to maintain the required protection rating.
Grounding: Always connect the functional ground terminal to the system earth to ensure electromagnetic compatibility and user safety.
Communication Cables: Use specified shielded cables for TTY/V.24 and MPI/DP connections to prevent signal interference from industrial noise.
Environment: Protect the rear of the device from excessive heat, conductive dust, and vibration within the enclosure.
Programming: Configuration of the operator panel requires the appropriate legacy HMI programming software supported by the OP15 series.
